AXIS P7701 - System Options
SMTP (email)
Enter the host names (or IP addresses) and port numbers for your primary and secondary mail servers in the fields provided, to
enable the sending of notifications from the decoder to predefined addresses via SMTP.
If your mail server requires authen
tication, check the box for Use authentication to log in to this server and enter the
necessary information. See the online help for more information.
SNMP
The Simple Network Management Protocol (SNMP) allows remote management of network devices. An SNMP community is
the group of devices and management station running SNMP. Community names are used to identify groups.
Depending on the level of security required, select the version of SNMP to use. The
three levels of security are:
SNMP v1/v2 - Select either SNMP V1 that includes no security,
or SNMP V2c that uses very simple security.
The community name can be specified as a password for read or read/write access to all
supported SNMP objects. The
community is the group of network devices using SNMP. The default password for the Read Community is public and the
default password for the Write community is write.
Traps for SNMP v1/v2
Traps are used by the decoder to send messages to a managemen
t system for important events or status changes.
If En
able traps is selected, enter the IP address where the trap message is to be sent as well as the Trap community that
should receive the message.
There are four types of traps available for the video decoder.
• Cold start
•Warm start
•Link up
• Authentication failed
SNMP v3 - SNMP V3 - provides encryption and secure passwords. HTTPS must be enabled. To use traps with
SNMP v3 an
SNMP v3 management application is required.
If the Enable S
NMP v3 option is enabled, provide the Initial user password. Note that the initial password is activated only
when HTTPS is enabled and can only be set once.
If HTTPS is enabled, SNMP v1 and
SNMP v2c should be disabled.
When SNMP configuration is ready, click Save to use the new settings or Reset to return to the default values.
UPnP™
The video decoder includes support for UPnP™. UPnP™ is enabled by default, and the video decoder then is automatically
detected by operating systems and clients that support this protocol.
Bonjour
The video decoder includes support for Bonjour. When enabled, the decoder is automatically detected by operating systems
and clients that support this.
Ports & Devices
This page allows configuration of the COM port. For more information please see the online help .
