Technical Specifications for AXIS P7701
Technical Specifications
Function/group Item Specification
Decoder Models AXIS P7701 Video Decoder
Video Video compression • H.264
• MPEG-4 Part 2
• Motion JPEG
Resolutions • H.264 and MPEG-4 Part 2; All resolutions up to D1 (720x480 in NTSC,
720x57
6 in PAL)
• Motion JPEG; All resolutions up to 720p (1280x720)
Frame rate H.264 30/25 (NTSC/PAL) fps in up to D1 resolution
Frame rate MPEG-4
part 2
30/25 (NTSC/PAL) fps in up to D1 resolution
Frame rate
Mot
ion JPEG
Up to 15 (NTSC/PAL) fps in 720p resolution
Video streaming • One stream H.264/Motion JPEG
/MPEG-4 part 2 decoding
Image settings • NTSC/PAL
• VGA (60/75Hz)
• S-VGA (60/75Hz)
• 1280 x 720 (16:9) via DVI-I connector
Serial Connection Forwarding of serial commands
Audio Audio streaming One way
Audio compression • AAC-LC 8 kHz 32 kbit/s, 16 kHz 64 kbit/s
• G.711 PCM 8 kHz 64 kbit/s
• G.726 ADPCM 8 kHz 32 or 24 kbit/s
Audio input/output Line output
Network Security Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X
network
access control, digest authentication, user access log
Supported protocols IPv4/v6, HTTP, HTTPS, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II),
DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP,
SSL/TLS
System
Integration
Application
Programming
Interface
Open API for software integration, including VAPIX® from Axis
Communications available at www.axis.com
Alarm triggers Ability to receive external alarms according to specified VAPIX API
Alarm events Notification via email
General Casing • Metal casing. Standalone or wall mount
Processors, memory • TI TMS320DM6443, 128MB RAM, 128MB
Flash
Power 8-20 V DC, max. 8.3 W or Power over Ethernet IEEE 8
02.3af Class 3
Connectors • RCA composite video output
• DVI-I (digital and analog) output
• RJ-45 10BASE-T/100BASE-TX PoE
• DC terminal block: 8
-20 V DC max. 8.3 W
• I/O terminal block: input for a video select button, and a 3.3V @ 250mA
power output
• RS485/ RS422 terminal block
• 3.5 mm audio line/headphones output, mono
Operating conditions • 0-50 °C (32-122 °F) Humidity 20-80% RH (non-condensing)
Approvals • EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15
Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR22
Class B, IEC/EN 60950-1, KCC Class B
Dimensions (HxWxD) 33 x 99 x 118 mm
Weight • 318 g (0.7lb)
