Page 62
Chapter 4
Installation Instructions
DISH 500 with a DishPro Twin LNBF, One DISH 300 with a
DishPro LNBF, DP34 Switch, Four DishPro Receivers
This diagram leaves out grounding to be clear. Make sure you
ground the system per the National Electrical Code (NEC) and all
local electrical codes.
When you set up your system following this diagram and run Check Switch
the Installation Summary screen should look similar to the one shown
below.
Two DP34s for
Eight DishPro Receivers
Three DP34s for
Twelve DishPro Receivers
