Page 84
Appendix A
Warning: Tighten all the coaxial cable connections only by hand.
Using a wrench may over-tighten the connections, causing damage.
Such damage is not covered by the Limited Warranty.
2. Connect a coaxial cable from the
TV SET OUT connection on your
receiver to your television's RF tuner input. Peel off the white sticker
and affix it to the cable close to where it connect to the TV SET OUT
connection on the back of the receiver.
3. Plug in the receiver's power cord. Make sure both the receiver and TV
are turned on.
4. You should see the
Point Dish/Signal Strength menu in the new
receiver. If you do not, open the Main Menu, by pressing MENU fol-
lowed by 6-1-1 on the remote.
5. Select Check Switch. Select Test to run Check Switch.
6. When Check Switch is complete, you will see an Installation Sum-
mary
screen. If the screen shows the correct switch and the message
"Satellite reception verified" for all satellites in your system, go to
step 7. If the Installation Summary screen does not detect all of the
satellites your system should be receiving, check and retighten (by
hand) the cable connections between your receiver, LNBFs and
switches in your system. Then press Test to rerun Check Switch
again.
7. Select
OK to return to the Point Dish/Signal Strength screen. Then
select Cancel to exit the Point Dish/Signal Strength screen.
8. An Attention screen will open asking if the mounting and positioning
of your dish is complete with a "Locked" indication in the Point
Dish/Signal Strength
screen. Since your system is already installed
and your dish is pointed for the strongest possible signal strength, you
can select
Yes.
9. The receiver will begin taking a software upgrade. You will see the
message shown below.
A progress bar at the bottom of the screen will show how the software
upgrade is progressing. Once the software upgrade is complete, you
will see a second message that the receiver's memory is now being
programmed.
This message may disappear, your screen may go blank for a few
minutes, and the green light may continue to blink. This is normal and
does not indicate a problem with the receiver.
10. When the software upgrade is complete, press VIEW TV and you
should now be able to watch TV programming. To activate your pro-
gramming on this newly installed receiver, call 1-800-333-DISH
(3474). See Chapter 1, Introduction.
