4.3 SETUP OF TV SIGNAL SYSTEM
If picture is not full screen or edge of the picture
has been covered or TV white-black phenomenon
exists, please press the NTSC/PAL button on the remote
control, adjust the whole player output system
according to TV system.
3. Connect with Optical-Digital Audio
Terminal or Coaxial Terminal.
Directly connect the optical or coaxial cord of the
amplifier with optical or coaxial terminal of this
player (this factory setting mode is SPDIF-PCM ),
then connect video terminal of the player with video
interface of TV.
When using optical or coaxial output function of this
player, please refer to 7.2 Audio setting up for the
detailed setup method.
Note: Pictures are possible to be less than full screen
or partially covered, because DVD discs can support
different picture proportions.
5. BASIC OPERATION
After connection, you must make the following
preparations before operating this player.
1. Switch the TV on and select "video input".
2. Connect the power wires of the player with the
socket.
Notes: When the icon " " displays on the TV screen,
it means that the current operation is invalid probably
resulting from maloperation or restriction of the discs.
