Jwin JD-VD503 DVD Player User Manual



7.2.2 SPDIF Setup
When this item is selected, the TV menu screen display
is as shown in the picture at right:
7.2.2.1 SPDIF Output
If the connected power amplifier has the function of
Dolby AC-3 decoding , it's best to select SPDIF RAW.
If the power amplifier doesn't have the decoding
function, but has coaxial or optical fiber input, it's best
to select SPDIF-PCM.
7.2.2.2 LPCM Output
When SPDIF output is set as SPDIF-PCM, it is used
for setting the sampling frequency of the output signal
of the optical fiber and coaxial terminal.
Note: This item shall be set cooperating with the disc
and power amplifier, or there may be no sound output.
7.2.2.3 Back
Select this item to return to the higher menu.
7.2.3 Dolby Digital Setup
7.2.3.1 Dynamic Scope Compression
Adjusting this item can gain different signal compression
effects. For example, you can adjust the linear
compression ratio higher when playing a disc in the
day so as to get a better acoustical effect; while at night,
you can adjust the ratio lower.
7.2.1.6 Dialogue
It is used for enhancing the definition of dialogue.
When the audio channel mode is 5.1 CH, it doesn't
have such a function.
7.2.1.7 Back
Select this item to return to the higher menu.
--SPEAKER SETUP PAGE--
DOWNMIX
FRONT SPEAKER
CNTR SPEAKER
REAR SPEAKER
SUB WOOFER
DIALOG
STEREO
5.1CH
BACK
--SPDIF SETUP PAGE--
SPDIF OUTPUT
LPCM OUT
BACK
SPDIF OFF
SPDIF/RAW
SPDIF-PCM
DYNAMIC
BACK
--DOLBY DIGITAL SETUP--
28
R
