2. Basic operations
2-6. Frame memory
AUX output signals can be stored in the frame memory for use. Stored images can be used as the bus images by
assigning the FMEM signals using the crosspoint assignment process.
Images stored in the frame memory are also saved in the unit’s flash memory so they can be used even after the
power is turned off. Stored images have an 8-bit format so their image quality may appear downgraded.
Press the [FUNC] switch to light its indicator, and then press the [MEM] switch to display the MEM menu.
Turn [F1] to display the MEM menu.
Press the [F4] switch (EXEC) to store the still images in the frame memory.
ＦＭＥＭ
３／３
ＳＩＧ
ＡＵＸ
ＭＥＭ
ＦＭＥＭ
ＳＴＯＲ
ＥＸＥＣ
Images can also be imported into the frame memory from a PC via Ethernet.
For details on how to transmit them, refer to “5. Image transmission functions”.
