40
4. Setting menu table
A setting is entered when an item is selected and then the [F1], [F2], [F3] or [F4] switch is pressed.
(It will not be entered unless the switch is pressed.)
Menu
Submenu Parameter 1 Parameter 2 Parameter 3
Turn F1 to select. Turn F2 to select. Turn F3 to select. Turn F4 to select.
TIME BKGD Parameter TIME UNIT
1/2 Setting range 0 to 13s 0 to 999f F
SEC
Default value
— 60f SEC
KEY Parameter TIME UNIT
2/2 Setting range 0 to 13s 0 to 999f F
SEC
Default value
— 60 SEC
WIPE BODR Parameter WIDT SOFT COLR
1/5 Setting range 0 to 255 0 to 255 WHT, YLW, CYN
GRN, MGT, RED
BLE, BLK
USR1 to 4
Default value
50 0 YLW
USR1(*) Parameter HUE SAT LUM
2/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
0 0 100
USR2(*) Parameter HUE SAT LUM
3/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
355 100 7
USR3(*) Parameter HUE SAT LUM
4/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
50 100 29
USR4(*) Parameter HUE SAT LUM
5/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
0 0 0
CBGD CBGD Parameter COLR — —
1/5 Setting range WHT, YLW, CYN
GRN, MGT, RED
BLE, BLK
USR1 to 4
— —
Default value
WHT
USR1(*) Parameter HUE SAT LUM
2/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
0 0 100
USR2(*) Parameter HUE SAT LUM
3/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
355 100 7
USR3(*) Parameter HUE SAT LUM
4/5 Setting range 0 to 359 0 to 100 0 to 108
Default value
50 100 29
