Close the session after recording. Play may be impossible on some discs due to the condition of the recording.
≥The producer of the disc can control how discs are played. So you may not always be able to control play as described in these operating
instructions. Read the disc’s instructions carefully.
≥Operation and sound quality of CDs that do not conform to CD-DA specifications (copy control CDs, etc.) cannot be guaranteed.
≥2.6 and 5.2 GB DVD-RAM, 12 cm
≥3.95 and 4.7 GB DVD-R for Authoring
≥DVD-R, DVD-R DL, DVD-RW, +R, +R DL recorded on another unit
and not finalised (> 81).
≥Discs recorded with AVCHD format.
≥DVD-Video with a region number other than “4” or “ALL”
≥DVD-Audio
≥Blu-ray, HD DVD
≥DVD-ROM, +R (8 cm), CD-ROM, CDV, CD-G, Photo CD, CVD,
SVCD, SACD, MV-Disc, PD, etc.
When you use the discs recorded either PAL or NTSC, or playback a
title recorded on HDD using PAL or NTSC, refer to this table.
(≤: Possible to view, –: Impossible to view)
§1
If your television is not equipped to handle PAL 525/60 signals
the picture will not be shown correctly.
§2
Select “NTSC” in “TV System” (> 63).
≥When playing back a disc or title recorded on the HDD, ensure that
you match the “TV System” setting to the disc or title (PAL or
NTSC) (> 63).
≥Despite meeting the conditions mentioned above, there may be USB memories that cannot be used for this unit.
≥If a Panasonic digital video camera with HDD etc. is connected to this unit’s USB port, you can copy the SD Video recorded with the camera to
this unit’s HDD or DVD-RAM.
≥This unit’s USB port does not support bus-powered USB device.
Play-only discs
Disc type Logo Standard symbol Uses
DVD-Video [DVD-V] High quality movie and music discs
DVD-RW (DVD
Video
Recording
format)
[-RW‹VR›] DVD-RW video recorded on another DVD recorder
≥You can play programmes that allow One time only recording if they
have been recorded onto a CPRM compatible disc.
≥
By formatting (
>
57) the disc, you can record onto it in DVD-Video format.
≥
It may be necessary to finalise the disc on the equipment used for recording.
DVD-R
DVD-R DL
DivX/MP3/WMA/
JPEG
≥DVD-R and DVD-R DL with video recorded in DivX
≥DVD-R and DVD-R DL with music recorded in MP3/WMA
≥DVD-R and DVD-R DL with still pictures recorded in JPEG
CD [CD]
Recorded audio and music (including CD-R/RW
§
)
– DivX/MP3/WMA/
JPEG
≥CD-R and CD-RW with video recorded in DivX
≥CD-R and CD-RW with music recorded in MP3/WMA
≥CD-R and CD-RW with still pictures recorded in JPEG
Video CD [VCD]
≥Recorded music and video (including CD-R/RW
§
)
Discs that cannot be played
Types of disc or title recorded on HDD
for the type of connected TV
TV type Disc/Titles recorded
on HDD
Yes/No
Multi-system TV PAL ≤
NTSC ≤
PAL TV PAL ≤
NTSC
≤
§1
(PAL60)
NTSC TV PAL –
NTSC
≤
§2
USB memory information
Compatible USB memories
USB memories which are defined as USB mass storage class, and digital cameras that use PTP protocol:
–USB memories that support USB 1.0/1.1 and USB 2.0 Full Speed/High Speed.
≥USB memories of up to 128 GB can be used.
≥USB memories that support bulk only transfer.
CBI (Control/Bulk/Interrupt) is not supported.
≥Digital Cameras which require additional programme installation when connected to a PC are not supported.
≥MTP (Media Transport Protocol) device is not supported.
≥A multi-port USB card reader is not supported.
Format FAT16 and FAT32 file systems are supported.
≥UDF/NTFS/exFAT file system is not supported.
≥Depending on the sector size, some files may not work.
≥Only the first partition on USB memories with multi-partition is supported.
Indicated in these instructions by
[USB]
Data that can be played or copied
(≤: Possible, –: Impossible)
File format DivX MP3/WMA Still pictures (JPEG)
Playing ≤≤ ≤
Copying to HDD – ≤≤
Instructions You can play DivX files recorded
with a computer onto the USB
memory (> 30).
You can play and copy to HDD MP3/
WMA files recorded with a computer
onto the USB memory (
>
31, 52).
You can play and copy to HDD or DVD-
RAM still pictures recorded with a computer
onto the USB memory (
>
32, 51).
Note
