RQT9306
Linked operations with the TV (VIERA Link “HDAVI Control
TM
”)
You can enjoy linked operations with the TV and receiver by using
“HDAVI Control”.
Preparation
1 Connect this unit to your TV using an HDMI cable or to your
receiver using an HDMI cable (> 67).
2 Set “VIERA Link” to “On” (> 63). (The default setting is “On”.)
3 Set the “HDAVI Control” operations on the connected equipment
(e.g., TV).
≥Set the input channel on VIERA to suit the terminal to be
used as “HDAVI Control”.
4 Turn on all “HDAVI Control” compatible equipment and select this
unit’s input channel on the connected TV so that the “HDAVI
Control” function works properly.
Also when the connection or settings are changed, repeat
this procedure.
What you can do with “HDAVI Control”
§1
This function is available with the TV that supports “HDAVI Control 3” or later.
§2
This button is available only when this unit is on.
§3
When this button is pressed, the playback image is not immediately displayed on the screen and it may not be possible to watch the contents
from where playback started.
In this case, press [:] or [6] to go back to where playback started.
§4
This function is available with the TV that supports “HDAVI Control 4”.
≥These functions may not work normally depending on the equipment condition.
≥About “HDAVI Control” function, read the manual of the connected equipment (e.g., TV) too.
What is VIERA Link “HDAVI Control”?
VIERA Link “HDAVI Control” is a convenient function that
offers linked operations of this unit, and a Panasonic TV
(VIERA) or receiver under “HDAVI Control”. You can use this
function by connecting the equipment with the HDMI cable.
See the operating instructions for connected equipment for
operational details.
≥VIERA Link “HDAVI Control”, based on the control functions
provided by HDMI which is an industry standard known as HDMI
CEC (Consumer Electronics Control), is a unique function that
we have developed and added. As such, its operation with other
manufacturers’ equipment that supports HDMI CEC cannot be
guaranteed.
≥This unit supports “HDAVI Control 4” function.
“HDAVI Control 4” is the newest standard (current as of
December, 2008) for Panasonic’s HDAVI Control compatible
equipment. This standard is compatible with Panasonic’s
conventional HDAVI equipment.
≥Please refer to individual manuals for other manufacturers’
equipment supporting VIERA Link function.
Download from the TV
§1
When you connect the unit to a TV for the first time, the station list data etc. are automatically copied from the TV to the unit and the TV stations
are assigned to the programme positions on the unit in the same order as on the TV (> 9).
Easy playback
When the TV is on and the following operations are performed, the TV’s input will automatically switch to HDMI input mode and the TV displays
the corresponding action.
(Picture or sound may not be available for the first few seconds.)
Press [FUNCTION MENU]
§2
, [1](PLAY)
§3
, [DIRECT NAVIGATOR], [GUIDE], [G-Code], [PROG/CHECK] etc.
Power on link
When the TV is off and the following operations are performed, the TV will automatically turn on and displays the corresponding action.
(Picture or sound may not be available for the first few seconds.)
Press [FUNCTION MENU]
§2
, [1](PLAY)
§3
, [DIRECT NAVIGATOR], [GUIDE], [G-Code], [PROG/CHECK] etc.
≥[DVD-V] [CD] [VCD] and MP3/WMA
The TV is automatically turned on when you insert the discs.
Power off link
When you set the TV to standby mode, the unit is also automatically set to standby mode. The unit is automatically set to standby mode even if
the FUNCTION MENU screen etc. is displayed during playback or when the unit set to a timer recording.
Even if the TV is set to standby mode, the unit will not be set to standby mode at the same time when recording, copying, finalising etc.
≥When this unit is connected to an “HDAVI Control” compatible Panasonic receiver with an HDMI cable, the receiver will also turn off.
About the Standby Power Save function
§4
Even with “Power Save” set to “Off” (> 64) (Quick Start mode), this unit turns to “Power Save” states (> 9) when Power off link works, so it is
possible to reduce the power consumption while this unit is in standby mode.
≥“Standby Power Save” setting is required to be activated on the TV.
≥When turning this unit on or off without using Power off link function, this unit will not turn to “Power Save” states.
Note
