RQT9306
Changing the unit’s settings
Signal Condition
You can check the quality and strength of digital broadcast signals.
Realign the aerial if you are receiving a poor signal.
When “Signal Condition” is displayed in grey and cannot be
selected:
1 Press [EXIT] to exit the screen.
2 Press [WXCH] to select a digital channel. “D” appears on the
unit’s display.
3 Display the Setup menu again (> 59).
Press [3, 4] to select “Signal
Condition” and press [OK].
The quality and strength of the
signal are shown.
Press [WXCH] to select the
channel.
Signal Quality
Below 2 (display red):
The signal quality is so poor that there may be interference in the
pictures and sound.
2–5 (display orange):
The signal quality is basically adequate, but brief interference in the
pictures and sound is possible in isolated case.
Over 5 (display green):
Optimum picture and sound quality.
Signal Strength
The display for signal strength is grey. “0” means signal strength 0%,
“10” means signal strength 100%.
If the signal is too strong, the display will change from grey to red.
Reduce the signal amplification at your aerial.
≥When the signal is weak:
–adjust the position and direction of the aerial.
–adjust the aerial reception with “DVB Manual Tuning” in the
Setup menu (> 59).
–check that the current digital broadcast channel is correctly
broadcasting.
∫ Settings for Analogue Channels
Press [OK] to show the following setting.
Manual Tuning
You can delete analogue channels and set the analogue channel
details.
Press [OK] to show Manual Tuning screen.
To delete a programme position
Press [3, 4, 2, 1] to select a programme position and press the
“Red” button.
To change the tuning settings for individual programme
position
1 Press [3, 4, 2, 1] to select a programme position and press
[OK].
2 Press [3, 4] to select an item and press [1].
Signal Quality 010
Signal Strength 010
DVB Channel
DVB Signal Condition
RETURN
Channel
+
Channel
–
[CH14] 5 BR3
Pos Programme position in the table
(You cannot change the programme position.)
Channel To enter or change the Channel of a TV
station
Press [3, 4, 2, 1] to enter station name
and press [OK].
If the station name needs a blank space,
select the blank between “Z” and “¢”.
CH To enter newly available TV stations or
change the CH number of an already tuned
TV station
Press [3, 4] or the numbered buttons to
enter the CH number of the desired TV
station.
Wait a few moments until the desired TV
station has been tuned.
After the desired TV station is tuned, press
[OK].
Fine Tuning To obtain the best tuning condition
Press [3, 4] to adjust the best tuning
condition and press [OK].
≥Press [1] to return to “Auto”.
Mono To select the type of sound to be recorded
Press [3, 4] to select “On” if the stereo
sound is distorted due to inferior reception
conditions, or if you want to record the normal
(mono) sound during a stereo or bilingual
broadcast, and press [OK].
Manual Tuning
Pos Channel CH Pos Channel CH
Delete
1 ARD 4
2 ZDF
2
3 N3
5
4 HR3
8
5 BR3 10
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
OK
RETURN
SELECT
Pos
Channel
CH
Fine Tuning
Mono
901
4
Auto
RETURN : leave
Manual
Tuning
ARD
Off
RETURN
SELECT
