The Initial Setup menu
14
111
En
English
•
Name
– Move the cursor right then input a name for
the current station, (up to five characters) then press
ENTER
.
•
Decoder
– If the current channel is scrambled,
requiring a decoder connected to the
AV2(INPUT 1/
DECODER)
connector, set this to
On
. (See also
AV2/
L1 In
on page 113.)
Channel Swapping
The preset swap feature lets you swap the channel
assignments of different programs. This is so that you
can group together station presets which naturally go
together.
1 Select ‘Channel Swapping’.
2 Select ‘Next Screen’ to go to the swap presets
screen.
3 Use the
/
(cursor up/down) buttons to select
a preset station to swap.
• Use the
PREV/NEXT
buttons to display the previous/
next page.
4 Press
(cursor right), then select a preset
station to swap with the first preset.
5 Press ENTER to swap the presets.
6 If you want to swap more presets, press
(cursor left), then repeats steps 3 to 5.
7 Press HOME MENU to finish and exit.
Video In / Out settings
Input Colour System
• Default setting:
Auto
On the default setting, the recorder automatically detects
whether the video signal from the built-in tuner or from
one of the external inputs is PAL, SECAM, 3.58 NTSC or
PAL–60. You may, however, occasionally need to set it
manually if the picture is not displayed properly.
1 Select ‘Input Colour System’, then ‘Next Screen’.
2 Use the CHANNEL +/– buttons or the INPUT
SELECT button to switch between the built-in tuner
and the external inputs.
3 Use the
/
(cursor left/right) buttons to
change the input colour system for the current input
or built-in tuner.
• The available settings depend on the Input Line
System setting (see
Input Line System
on page 108).
The table below shows the different options available.
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
Auto Channel Setting
Manual CH Setting
Channel Swapping
Next Screen
Initial Setup
11
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
[1] 1/17 [2] 1/17
Swap Preset
Initial Setup
51
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
[1] 1/17 [2] 1/17
Swap Preset
Initial Setup
53
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
Pr System CH
Name
1 I CC40
2 I 2
3 I 3
4 I 4
5 I 5
6 I 6
[1] 1/17 [2] 1/17
Swap Preset
Initial Setup
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
Input Colour System
Component Video Out
AV1 Out
AV2/L1 In
NTSC on PAL TV
Next Screen
Initial Setup
Auto
Pr 5
