The Initial Setup menu
14
114
En
External Audio
• Default setting:
Stereo
If the external source is standard stereo, leave set to
Stereo
. If each channel carries a separate soundtrack,
change to
Bilingual
.
When the external audio is from the DV input, an audio
subcode channel within the DV audio tells the recorder
whether the audio is stereo or bilingual. This has priority
over the setting you make here.
Bilingual Recording
• Default setting:
A/L
When recording a bilingual source from an external input
in Video mode or VR mode set to
FINE/MN32
, or to the
HDD, you can choose to record either the
A/L
(left), or
the
B/R
(right) audio channel.
1
DV Input
• Default setting:
Stereo1
You need to set this if you have a camcorder using 32kHz/
12-bit sound connected to the front panel
DV IN/OUT
jack.
Some digital camcorders have two stereo tracks for
audio. One is recorded at the time of shooting; the other
is for overdubbing after shooting.
On the
Stereo1
setting, the sound that was recorded
while shooting is used. On the
Stereo2
setting, the
overdubbed sound is used. You can also choose a
Mix
setting of 25%, 50% or 75% for the Stereo 1 with a
corresponding Stereo 2 setting of 75%, 50% or 25%.
Input Level (L1 / L2 / L3)
• Default setting:
0dB
You can adjust the gain of the audio from each external
input individually, from
–6dB
to
+6dB
in steps of 3 dB to
optimize the recorded audio level.
Audio Out settings
Digital Out
• Default setting:
On
If at any time you need to switch off the digital audio
output, set this to
Off
, otherwise leave it
On
.
Dolby Digital Out
You only need to make this setting if you connected this
recorder to an AV amp/receiver (or other component) using
the digital output.
• Default setting:
Dolby Digital
Note
1 If you’re recording in VR mode (except when set to
FINE/MN32
), both channels will be recorded and you can switch them as you like on play-
back.
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
NICAM Select
Tuner Level
External Audio
Bilingual Recording
DV Input
Input Level (L1)
Input Level (L2)
Input Level (L3)
Stereo
Bilingual
Initial Setup
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
NICAM Select
Tuner Level
External Audio
Bilingual Recording
DV Input
Input Level (L1)
Input Level (L2)
Input Level (L3)
A/L
B/R
Initial Setup
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
NICAM Select
Tuner Level
External Audio
Bilingual Recording
DV Input
Input Level (L1)
Input Level (L2)
Input Level (L3)
Stereo1
Stereo2
Mix (Stereo1: 75%)
Mix (Stereo1: 50%)
Mix (Stereo1: 25%)
Initial Setup
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
NICAM Select
Tuner Level
External Audio
Bilingual Recording
DV Input
Input Level (L1)
Input Level (L2)
Input Level (L3)
Initial Setup
+6dB
+3dB
0dB
–3dB
–6dB
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
Digital Out
Dolby Digital Out
DTS Out
96kHz PCM Out
MPEG Out
On
Off
Initial Setup
Basic
Tuner
Video In/Out
Audio In
Audio Out
Language
Recording
Playback
Digital Out
Dolby Digital Out
DTS Out
96kHz PCM Out
MPEG Out
Dolby Digital
Dolby Digital PCM
Initial Setup
