SHOCK AND VIBRATION
The table below lists the conditions and limits for shock and vibration for the LF 6602.
Shock and Vibration Criteria and Limits
1 With media removed 2 In LMS-approved packaging 3 Shock repetition rate should be limited to allow mechanical
system transients to subside between pulses. 4 Limit at 5.0 g peak for LF 6602 cabinet. Limit at 3.0 g peak in
LF 6600/LF 6602 in front-to-back axis because media in shuttle will be displaced. The drive is not designed for pro-
longed operation at these shock levels.
AC POWER REQUIREMENTS
The primary AC power cord type will depend on the LF 6602 configuration ordered. The primary AC power
cord supplies power to the power socket strip located within the LF 6602 cabinet. Each LF 6602 is
connected to the power socket strip with a grounded AC power cord. The power connector of each
LF 6600 is integrated into the AC power receptacle. Over current protection is provided by two fuses,
which are also integrated into the receptacle with two spare fuses. Refer to the Replacing Fuses section
for the fuse replacement procedure.
Each drive's power supply accepts the input line voltages listed in Table 3. The power supply is
autoranging and does not require mechanical switching for input voltage or frequency selection.
AC Power Requirements
1 Less than 1 sec, cold start
NOTE
After the power has been turned off, the operator must wait 1 second
before turning on the power again
CONDITION OPERATING
NONOPERATING
1
STORAGE/TRANSIT
2
Swept Vibration
(Bidirectional)
1 Octave/Min
5 to 22 Hz 0.01 in
Double Amplitude,
22 to 500 Hz
0.25 g Peak
5 to 44 Hz, 0.03 in
Double Amplitude,
44 to 500 Hz
3.0 g Peak
5 to 44 Hz, 0.03 in
Double Amplitude,
44 to 500 Hz
3.0 g Peak
Shock
3
(Host Retries May
Be Required and
Drive Performance
May Degrade During
Test
10 - msec Half Sine
Pulse of 5.0 g Peak
4
Unpacked (3 Axis) 5 - msec Half Sine
Pule of 5.0 g Peak
Packed on Pallet 31 - cm (18 - in)
Drop Test Flat
FREQUENCY AC VOLTAGE
CURRENT
(TYPICAL)
SPIN - UP
SURGE
1
MINIMUM
SERVICE
RATINGS
47 to 66 Hz 86.7 to 128 V 3.0 A 10.0 A 15 A
47 to 66 Hz 173.4 to 268 V 1.5 A 5.0 A 15 A
