KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating the VP-747
32
9.1.3 The Audio Menu Items
The audio menu controls the VP-727A audio companion. See the VP-727A
user manual for further detail
2
. Figure 15 and Table 9 define the screen.
Figure 15: Audio Screen
Table 9: Audio Screen Functions
Setting Function Selection/Range Default
Program Source Channel 1 to Channel 8 Channel 1
Input Volume -82 (mute) to +45 0
Output Volume -22 (mute) to +9 0
Delay
3
0 to 127 [msec] 0
Preview Source Channel 1 to Channel 8 Channel 1
Input Volume -82 (mute) to +45 0
Output Volume -82 (mute) to +45 0
Headphones Set the headphone source Program or Preview Program
Volume -12 (mute) to 4 0
Calibration Bass -6 to 6 0
Treble -6 to 6 0
Balance -10 to 10 0
Option Audio-Follow-Video Follow or audio breakaway Follow
Fade On or Off On
Mute-Follow Freeze, Blank or Freeze & Blank none
Take In the breakaway mode, preview
and program audio inputs switch
positions
1 If the resolutions of Preview and Program are different, pressing the TAKE button when in the Freeze mode, will disable
the Freeze mode
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 Sets the pipeline delay of the audio (to compensate the delay in the video processing)
