Setting Analog Audio
Connections to an AV Amplifier
or Receiver
This player is capable of both 2 channel stereo and 5.1
multichannel surround sound audio output. Use this setting to
select which analog outputs are connected to an AV
component.
Make adjustments in the [Audio Out] setting in the Setup
screen Audio 2 menu.
Settings: 2 Channel*
5.1 Channel
*Factory setting
Audio Out
Speaker Setting –
Gain Setting –
CD Digital Direct – Off
Audio DRC – Off
Move
Exit
2 Channel
5.1 Channel
Fix
SETUP
Audio1 Audio2 GeneralLanguageVideo
About source audio output
When the source output mode has been switched between the [5.1 Channel] and [2 Channel] mode settings using the [Audio Out]
setting in the Setup screen Audio 2 menu, audio output for each source will be as shown on the following table.
AUDIO
CONTENTS
OUTPUT
MODE
AUDIO OUT (2 CH)
5.1 CH
2 CH
5.1 CH
2 CH
5.1 CH/
2 CH
5.1 CH
2 CH
5.1 CH/
2 CH
5.1 CH/
2 CH
DVD
CD
VIDEO CD
Dolby
Digital
Dolby
Digital
Karaoke
LPCM
DTS
DVD
-Audio
Front Lch, Rch
2 ch DOWNMIX Lch, Rch
2 ch DOWNMIX Lch, Rch
2 ch DOWNMIX Lch, Rch
MUTE
Center
Rear LS, RS
2 ch DOWNMIX Lch, Rch
Lch, Rch
Lch, Rch
AUDIO OUT (5.1 CH)
DIGITAL OUTPUT (S/PDIF)
Lch, Rch
Front Lch, Rch
LEFT, RIGHT (Front L,R)
Center Surround L,R
Sub Woofer
Dolby Digital or
MPEG 3 PCM
Dolby Digital or
MPEG
Dolby Digital
Lch, Rch
DTS
***
****
**
*
Center
Rear LS, RS
LFE
LFE
MUTE
Lch, Rch
MUTE
MUTE
Dolby Digital
Lch, Rch
Lch, Rch
MUTE
MUTE
5.1 CH/
2 CH
DVD-RW
(USA model only)
Lch, Rch
Dolby Digital, MPEG or
PCM (Lch, Rch)
MUTE
2 ch DOWNMIX
Lch, Rch
5.1 CH
2 CH
Front Lch, Rch
Lch, Rch
Center
Rear LS, RS
MPEG
LFE
MUTE
5.1 CH
2 CH
Front Lch, Rch
Center
Rear LS, RS
LFE
MUTE
MPEG
Lch, Rch
Lch, Rch
*: When the Setup screen Audio 1 menu [DTS Out] setting is set to [Off], DTS digital output is muted.
**: Discs that prohibit downmixing will be output as 5.1channel even if [2 Channel] is selected.
***: Discs that prohibit downmixing also mute the digital output.
****: If the sound is mono, Lch and Rch audio will be the same.
Notes
• When [5.1 Channel] is selected, the front right (R) and left (L)
audio channels are output from the AUDIO OUTPUT LEFT and
RIGHT jack.
• If the center or surround components are not recorded on the
disc, there will be no output from the CENTER or SURROUND
output jacks. This is not a malfunction. The audio channels
present on the disc can be verified in the program format
indicators in the display.
ADJUSTING AUDIO AND VIDEO SETTINGS
