● LIVE
Split Mode Menu
In Live split mode, right-click to display this context menu as shown.
The context sensitive menu in split mode differs, depending on the login/logout status.
Menu Description
a
Screen Mode
Select a screen mode for the Live screen.
Refer to “Live screen mode”. (Page 32)
b
CH Info
It displays the camera connection information for each channel.
Refer to the “Channel Information”. (Page 33)
c
Live Status
Shows the live status of connected camera to each channel.
Refer to “Live Status”. (Page 34)
d
Record Status
Shows the record status of each channel.
Refer to “Record Status”. (Page 34)
e
PoE Status
Set the PoE status in each channel.
Refer to the “PoE Status”. (Page 36)
f
Audio On/Off
Turns ON/MUTE the sound of the selected channel.
Refer to “Audio ON/OFF”. (Page 36)
g
Freeze Stop playing the video temporarily. Refer to “Freeze”. (Page 37)
h
Stop Alarm
Stop the alarm output, deactivate the event icon and release the auto sequencing.
Refer to "Event Monitoring". (Page 37)
i
Record/Stop Starts/stops the standard recording.
Scene Mode ►
CH Info
Live Status
Record Status
PoE Status
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Menu
Quick Setup ►
Shutdown
Hide Launcher
Logout
c
b
a
d
m
q
n
l
p
k
o
j
i
h
g
f
e
