Getting Started
16
Connecting the TV
To display clear crisp pictures, you must connect your TV correctly and
select the correct Wide Mode to display the picture in the correct aspect
ratio (see “Changing the Wide Screen Mode” on page 31). It is strongly
recommended that you connect the antenna/cable input using 75-ohm
coaxial cable to receive optimum picture quality signal. A 300-ohm twin
lead cable can be easily affected by radio noise and the like, resulting in
signal deterioration. If you use a 300-ohm twin lead cable, keep it as far
away from the TV as possible. Do not use an indoor antenna, which is
especially susceptible to radio noise.
You can also connect a variety of optional equipment to your TV (see page
17). For multiple equipment connections, please refer to the separate Quick
Setup Guide.
Cable System and
VHF/UHF Antenna
System
Cable Box/Digital
Cable Box and
Antenna
Use this hookup if
❑ Your cable company scrambles some channels, such as premium
channels. Viewing all channels requires a cable box.
❑ You do not intend to hook up any other audio or video equipment to
your TV.
✍ Press ANT to switch between VHF/UHF and cable.
Antenna cable
CATV cable
z
To change channels
using the cable box, set
your TV to channel 3 or
4 depending on the
cable box channel
output.
✍ To set up the TV remote control, see “Programming the Remote
Control” on page 32.
✍ Press SAT/CABLE to begin operating the cable box with the remote
control (see page 28). The indicator will light up.
✍ Press ANT to switch between VHF/UHF and cable.
VHF/UHF
CABLE
IN OUT
CATV cable
Rear of TV
Cable box
Coaxial
cable
Antenna
cable
