2 − Names and functions
14 TASCAM DV-RA1000HD
The following keys function in the same way as those
of the same name on the main unit. For the function
description, refer to the “Front panel” section in the pre-
vious pages.
OPEN/CLOSE
DISPLAY
EFFECT
MONITOR
MENU
CANCEL
F1 - F5
*1
)
•
•
•
•
•
•
•
ENTER MUTE
REC
*2
)
STOP PLAY
READY
MARK
*1) The
F1
-
F4
keys are arranged as cursor keys on the
remote control unit, duplicating one of their most com-
mon functions. The
F5
key is labeled as
HOME
/
F5
key,
and is often pressed to display the home screen.
*2) The
REC
key corresponds to the
RECORD
key on
the main unit.
•
•
•
•
•
Keys that features the same functions as those on the main unit
h
/ keys and / keys
These are separate keys on the remote control unit,
but are the same key on the main unit (short press
for skip, long for search). (See “Basic playback
operation” on page 30.)
j
A-B key
Enables you to set and perform A-B repeat. Note
that you can set A-B repeat only from the remote
control unit. (See “A-B repeat” on page 31.)
k
Number keys and CLEAR key
Enables you to select a track directly by pressing
the number keys, and set a programmed playback.
The
CLEAR
key is used to clear the current num-
ber entered at the 10's digit via the
+10
key. (See
“Programmed playback” on page 30.)
l
LOCATE key
Displays the locate point list for location and edit-
ing. (See “About marks” on page 39.)
;
JOG/DATA (+/–) keys
Functions the same as rotation of the
JOG/DATA
dial on the main unit, clockwise and counter-clock-
wise.
Keys found on only the remote control unit
Remote control unit
Figure 2.2: Remote control unit
k
j
h
l
;
k
j
h
l
;
