3 − Connections
TASCAM DV-RA1000HD 17
Other connections
WORD SYNC The DV-RA1000HD is fitted with three
BNC connectors for standard word sync.
CAUTION
There should be one, and only one clock master in
a setup.
IN receives word sync from an external source, and
OUT is used when the DV-RA1000HD is used as the
word sync master in a setup, outputting the frequency
of the current project. THRU echoes the sync received
at IN and is terminated automatically if nothing is con-
nected.
NOTE
When in DSD recording mode, the DV-RA1000HD
inputs and outputs word sync at 44.1 kHz. Under
these conditions, the input sync can be ±6% away
from the norm.
USB Connect a suitably-equipped computer using a
USB 2.0 cable. The DV-RA1000HD appears as a mass
storage device, requiring no driver software.
USB connection enables you to transfer audio files on
the HD of DV-RA1000HD to the computer, and transfer
audio files on the computer to the DV-RA1000HD. (See
“Use with a computer” on page 59.)
CONTROL I/O You can use RS-232C serial control
with the DV-RA1000HD by connecting an appropriate
cable to this connector. Consult your TASCAM distrib-
utor for details of pin-outs, protocols, etc.
REMOTE IN Connect only the supplied wired
RC-RA1000 remote control unit to this jack. Since the
remote control unit is a wired unit, the DV-RA1000HD
will respond to the key presses on the remote control
unit precisely. It does not require any batteries, and you
do not need to point at the DV-RA1000HD for opera-
tion.
PHONES Connect a standard set of stereo headphones
to this front panel 1/4" jack. Adjust the level with the
control above the jack.
KEYBOARD (front panel) Connect a computer
PS/2 keyboard (US standard layout) to this jack located
on the right side of the front panel to name files and
projects, and to create project notes.
