4 − Basic operations
TASCAM DV-RA1000HD 23
The virtual front panel (VFP)
The DV-RA1000HD allows access to many functions
through the virtual front panel, providing a graphical
representation of many of the keys and controls that
might be hardware switches on other units.
Note that many of these functions are hardware keys on
the remote control unit.
To launch the virtual front panel
1 From the home screen, press the ENTER key.
The virtual front panel appears.
There are four types of the virtual front panel:
“PLAY”, “REC”, “CD”, and “etc.”
Press CANCEL to exit the virtual front panel
and return to the home screen.
2 Press the function key (F1 - F4) that corresponds
to the tab on the bottom of the screen to display
the desired panel.
Figure 4.5: Virtual front panel (PLAY)
Figure 4.6: Virtual front panel (REC)
Figure 4.7: Virtual front panel (CD)
Figure 4.8: Virtual front panel (etc.)
•
Each panel features the switches to which various
functions are assigned.
3 Rotate the JOG/DATA dial to select a switch in the
panel.
4 Use the F5 (PUSH) key or ENTER key to press the
selected switch.
If a switch just toggles between on and off, a
mark appears above the switch when the switch
is turned on, and a mark appears above the
switch when the switch is turned off.
NOTE
In this manual, the procedure of selecting a
switch in the virtual front panel and pressing the
F5 key is referred to as “pressing a switch.”
Some switches, when pressed for at least one
second, present a menu of choices, but others
just toggle between on and off.
Play page
ARDY (auto-ready) Is used to switch auto-ready play-
back mode on and off. (See “Auto ready” on page 32.)
SNGL (single) Turns single-track playback mode on and
off. (See “Single track playback” on page 31.)
NOTE
The single play function cannot be used with the
repeat function. If either the single play or repeat
function is enabled, it is disabled when the other
function is enabled.
ACUE (auto-cue) Turns the auto-cue function on and
off. (See “Auto cue” on page 32.)
RPT (repeat) Sets the playback repeat mode between
OFF (off), ALL (all tracks of the disc are repeated)
and 1Tr (the current track is repeated). (See “Repeat
playback” on page 31.)
ASPC (auto-space) Turns the auto-space function on
and off. (See “Auto space playback” on page 31.)
PGM (program) Turns programmed playback on and
off, and allows setting of the programmed playback
mode. (See “Programmed playback” on page 30.)
FADE (fade) Turns the fade playback on and off. (See
“Fades” on page 33.)
Rec page
ATRK (auto-track) Turns the auto track function on
and off when recording. (See “Auto track increment” on
page 34.)
•
•
