TASCAM DV-RA1000HD 61
Analog I/O
Balanced inputs
Connector: 3-pin XLR female x 2 (1: GND, 2: Hot, 3: Cold)
Input impedance > 10 k
Ω @ 1 kHz
Nominal input level +6 dBu (at max. +15 dBu), +4 dBu (at all other levels)
Maximum input level
+15 dBu, +18 dBu, +20 dBu, +22 dBu, +24 dBu (switchable)
Unbalanced inputs
Connector Unbalanced RCA pin jacks x 2
Input impedance > 10 k
Ω @ 1 kHz
Nominal input level –10 dBV
Maximum input level +6 dBV
Balanced outputs
Connector 3-pin XLR male x 2 (1: GND, 2: Hot, 3: Cold)
Output impedance 220
Ω
Nominal output level
+6 dBu (at max. +15 dBu), +4 dBu (at all other levels)
Maximum output level
+15 dBu, +18 dBu, +20 dBu, +22 dBu, +24 dBu (switchable)
Unbalanced outputs
Connector Unbalanced RCA pin jacks x 2
Output impedance 220
Ω
Nominal output level –10 dBV
Maximum output level +6 dBV
Phones output (stereo)
Connector 1/4 " stereo jack (T = L, R = R, S = GND) x 1
Max output power 80 mW + 80 mW (30
Ω)
Digital I/O
PCM inputs (XLR)
Connector: 3-pin XLR female x 2 (1: GND, 2: Hot, 3: Cold)
Signal type IEC-60958-4, AES-3-1992
Input frequencies (kHz) 44.1/48, 88.2/96 (double-speed or double-wire), 176.4/192 (double-speed + double-wire)
all ±6%
Data format 16-bit (44.1 kHz, CD-DA), 24-bit (PCM recording to DVD±RW or HD)
Input impedance 110
Ω ±20%
Nominal input level 2–7 Vpp
Minimum signal level 200 mVpp
Intrinsic jitter <0.025UI (4 ns @ 48 kHz)
PCM inputs (RCA)
Connector: RCA (pin) jack x 1
Signal type IEC-60958-3
Input frequencies (kHz) 44.1/48, 88.2/96 (double-speed ), all ±6%
Data format 16-bit (44.1 kHz, CD-DA), 24-bit (44.1 kHz/48 kHz, 88.2/96 kHz to
DVD±RW or HD)
Input impedance 75
Ω ±20%
Nominal input level 0.5 Vp-p
Minimum signal level 0.2 Vp-p
Intrinsic jitter <0.025UI (4 ns @ 48 kHz)
10 − Specifications, etc.
