Chapter 3 Shooting
40 Chapter 3 Shooting
• Internal parts of the DSR-1/1P may become bent or otherwise
damaged if you attempt to close the cassette holder after inserting a
mini-size cassette in the wrong direction (such as with the cassette
turned backside front so the reel holes face the cassette holder
window or with the cassette turned sideways so that a short side
enters first).
•If
CL
appears in the display window when the cassette is loaded, it
means that data has already been recorded into the cassette memory.
If you record under this condition whether the ClipLink function is
available or not, the existing cassette memory data will be
overwritten. To avoid this, insert a new cassette.
• After inserting the cassette, close the cassette holder solidly by
pressing on the “PUSH” indication on the holder. Unless the cassette
holder is closed solidly, the tape will not be loaded and the tape
operation buttons will not function. If you find the tape operation
buttons inoperable, press on the “PUSH” indication again to make
sure that the cassette holder is solidly closed.
3 Make the switch settings shown in the figure below.
Shooting
Do not insert cassette backside front.Do not insert cassette sideways.
∞
H MIN SEC FRM
1
dB
2
PB DATE NDF EXT-LK HOLD
CLIP
TAPE
BATT
DIAG
EF
RF SERVO HUMIDSLACK
Li
-
-40
-30
-12
0
IP
CL
CONT
OVER OVER
WARNING
RESET
(MENU SET)
MENU ADVANCE SHIFT
ALARM
MONITOR
PRESET
DATE/TIME
ClipLink CONTINUE
MONITOR SELECT
BACK TALLY
LIGHT
DISPLAY
AUDIO LEVEL
AUDIO SELECT
AUDIO IN
CH-2
CH-1
OFF
ON
MIX
REGEN SET
F-RUN
R-RUN
AUTO
MANUAL
CAM
REAR
ON
OFF
COUNTER
TC
U-BIT
CH-1 CH-2
-20
DVCAM
F8
32k
F8
48k
TC mode switch 2: F-RUN or R-RUN
b)
TC mode switch 1: PRESET
b)
AUDIO SELECT
(CH-1/CH-2)
switches: AUTO
a)
a) When this switch is set to MANUAL, the recording volume can be manually
adjusted. For details, see “Manually adjusting audio recording level” on page 42.
b) For details, see “Setting Time Code Value” on page 51.
