Specifications A-3
Electrical Power
(continued)
Primary Dryer (optional)
◆ Power used: 200-240 VAC, 16 Amps maxi-
mum when operating, 50-60 Hz
◆ Required circuit: 200-240 VAC, 20 Amps,
with NEMA L6-20R (United States and
Japan) or CEE 7/7 (Europe) receptacle
If your building receives power from a standard
U.S. 208 VAC/60 Hz/three-phase supply, note
that the heater will use only one of the three
phases. This means that your building’s three-
phase power transformer will have an unbal-
anced load. Check with your electrician to verify
that your building has sufficient capacity for
this unbalanced load.
If the supplied power cord is connected, the
heater operates during printing, and may be
turned on or off at the printer control panel. If
not connected, this heater will not operate, but
the dryer fans will still operate when activated.
Secondary Dryer (optional)
◆ Power used: 200-240 VAC, 12.0 Amps maxi-
mum when operating, 50-60 Hz
◆ Required circuit: 200-240 VAC, 15 Amps, with
NEMA 6-15R (United States and Japan) or
CEE 7/7 (Europe) receptacle
If the supplied power cord is connected, this
heater operates during printing, and may be
turned on or off at the printer control panel. If
not connected, this heater will not operate, but
the dryer fans will still operate when activated.
Temperature Storage: 0–120° F (-17–49° C)
Operating: 60–90° F (16–32° C)
Relative
Humidity
Storage: 10–80%, non-condensing
Operating: 10–80%, non-condensing,
30–60% optimum
Built-in humidity sensing automatically adjusts
printing speed to ensure adequate drying for
the combination of media and ink selected
Approvals Safety: UL, c-UL, CE
Emissions: FCC-A, CE, VCCI-1
Immunity: CE
