ENGLISH
5
T-V LINK Functions
■ When a T-V LINK compatible VCR is connected to the EXT-2 Terminal on the TV, the procedures for setting up the VCR and
viewing videos are simplified.
■ T-V LINK uses the following features:
■ To use T-V LINK:
• a T-V LINK compatible VCR is necessary.
• the VCR must be connected to the EXT-2 terminal on the TV by a fully wired
SCART cable.
■ T-V LINK compatible VCRs:
In addition to all JVC VCRs that have the T-V LINK logo, any VCR that has one of
the following logos are available for use:
“Q-LINK” (a trademark of Panasonic Corporation)
“Data Logic” (a trademark of Metz Corporation)
“Easy Link” (a trademark of Phillips Corporation)
“Megalogic” (a trademark of Grundig Corporation)
“SMARTLINK” (a trademark of Sony Corporation)
• These VCRs may support some or all of the features described above. For de-
tails, refer to the VCR Instruction Manual.
■ When “FEATURE NOT AVAILABLE” is displayed:
If “FEATURE NOT AVAILABLE” is displayed after download execution, the down-
load was not performed correctly. Confirm the following before re-executing down-
load:
• that the VCR power is turned on.
• that the VCR is T-V LINK compatible.
• that the VCR is connected to the EXT-2 terminal.
• that the SCART cable is fully wired.
■ Operating Precautions for DIRECT REC:
• Generally, the VCR cannot record a channel that cannot be received properly by
the VCR’s tuner even though that channel could be viewed on the TV.
• In the following conditions, the VCR will stop recording if the TV is turned off, if
the TV channel or input is switched, or if the menu is displayed on the TV:
– When recording images from an external device connected to the EXT-1,
EXT-3 or EXT-4 terminal.
– When recording a channel after it has been unscrambled on a decoder.
– When recording a channel by using the TV’s output because that channel can-
not be properly received on the VCR’s tuner.
Function Features Remarks
1
Preset
Download
Downloads the PR channel tuning information from
the TV to the VCR.
•Starts automatically when the initial setting is
complete or whenever the Auto Program or Edit/
Manual operations from the Install menu are per-
formed.
•This function can be operated via VCR operation.
2
DIRECT REC
(WYSIWYR)
– What You See Is What You Record –
You can record to VCR the images that you are
currently viewing on TV by one-touch operation.
For details, read the manual for your VCR.
•Operate via the VCR. (Operation via the TV is not
possible.) “VCR IS RECORDING” is displayed.
3
TV Auto
Power On
VCR Image
View
When the VCR starts playing, the TV automatically
turns on and switches to the EXT-2 input mode.
•This function does not operate if your TV’s main
power is turned off. Set your TV’s main power to
on (standby mode).
When the VCR menu is operated, the TV automat-
ically turns on and switches to EXT-2 input mode.
Note:
• Not all VCRs support this type of
data communication. Some may
support certain features and not
support others. For complete
details, refer to the VCR Instruc-
tion Manual.
Note:
• Some VCRs can record a chan-
nel by using the TV’s output if
that channel can be viewed on
the TV, even though the channel
cannot be received properly by
the VCR’s tuner.
For details, refer to the VCR In-
struction Manual.
