RQT9431
HDD
Manual Recording
Preparation:
Connect a satellite or cable receiver to this unit’s
input terminals (➔ 109).
When the output signal from the external
equipment is NTSC, change the “TV System” to
“NTSC” in the Setup menu (➔ 101).
•
•
With the unit stopped
to select “AV2” for the
satellite or cable receiver you
have connected.
to select the HDD drive.
to select the recording mode.
DR, HG, HX, HE, HL, FR mode cannot be
selected.
Select the channel on the satellite
or cable receiver.
to start recording.
–
Tips
To skip unwanted parts
Press [
h
] to pause recording. (Press again to restart recording.)
To stop recording
Press [
g
].
Linked timer recordings with
external equipment (SKY Digital
STB, satellite/cable receiver)–EXT LINK
To record programmes from a SKY Digital STB,
satellite/cable receiver using timer programming
Preparation:
Make sure you connect the AV2 input terminal of this
unit to “VCR Scart Terminal” of a SKY Digital STB,
satellite/cable receiver with a 21-pin scart cable (➔ 109).
Set the “AV2 Input” and “Ext Link” to match the
connected equipment in the Setup menu (➔ 102).
•
•
Make timer programming on SKY
Digital STB, satellite/cable receiver.
Refer to the equipment’s operating instructions.
to select the HDD drive.
“EXT-L” lights on the unit’s display to indicate
timer recording standby has been activated.
The guidance information of EXT LINK appears.
–
–
–
Tips
To set external link standby using the FUNCTION MENU display
Perform step (➔ above)
1. Press [FUNCTION MENU].
2. Press [
e
,
r
] to select “Others”, then press [OK].
3. Press [
e
,
r
] to select “Ext Link Standby”, then press [OK].
4. Press [
w
,
q
] to select “Yes”, then press [OK].
To cancel the external control
Turn on this unit.
Press [EXT LINK] to stop recording or to cancel linked timer
recording standby (“EXT-L” disappears.).
Notes
During EXT LINK standby mode or recording, you cannot press
[INPUT SELECT] to select external input other than AV2.
In order to prevent accidental operation, press [EXT LINK] to cancel
the setting after recording is finished.
This function does not work when “TV System” is set to “NTSC” in
the Setup menu (➔ 101).
This function does not work with some equipment. Refer to the
equipment’s operating instructions.
The beginnings of recordings may not be recorded correctly in
some cases.
When “Ext Link” is set to “Ext Link 2”, this function does not work if
the input signal is NTSC system.
Programmes are recorded as one title on this unit when the end
time of the earlier timer recording and the start time of the later
timer recording are close to each other.
To divide the titles, go to “Divide Title” (➔ 52).
While the unit is in EXT LINK standby mode or recording, AV1
output terminal outputs the signal which is input from the AV2 input
terminal irrespective of “AV1 Output” setting (➔ 102).
EXT LINK recording is available on HDD only.
During EXT LINK standby mode or recording, playback is available
on both HDD and DVD drive. However, during EXT LINK recording,
DVD-Video, still pictures or music cannot be played back.
When “EXT-L” lights on the unit’s display, Direct TV Recording is
unavailable.
•
•
•
•
•
•
•
•
•
•
•
Recording from a Satellite or Cable Receiver
