16
LCD Display and On-Screen Content
On-Screen Content
In addition to E-E and playback screens, the monitor connected to the DVD recorder’s VIDEO LINE OUT terminal can display the
following.
● Status messages
● Event messages
● Alarm messages
● The Setup Menu (☞ Page 74)
● Recording-operation control screens: REC CONTROL panel (☞ Page 41)
REMOTE CONTROL screen ( ☞
Page 60)
Status Messages
The DVD recorder’s setting condition and operation status are indicated by status messages, and these messages are displayed
on E-E or playback screens.
The DISPLAY MENU screen can be used to indicate whether or not status messages are to be displ
ayed.
000 min
04/05/04
11:20:00
TITLE 1 0:11:22
CHAPTER
1 0:11:22
REC
DISPLAY MENU screen
Ⅵ To display status messages:
Set DISPLAY from the DISPLAY MENU screen to ON.
Ⅵ The various items of status information for display can be selected.
Ⅵ If DISPLAY is set to OFF, no status information will be displayed.
Status Messages
1
Data relevant to recording:
If the SET UP button is pressed
while in Recording mod
e, the
video bit-rate setting and the audio
encoding format will be displ
ayed.
If the SET UP button is then
pressed once again, this
information is removed from the
screen.
No. Item Description
1
Operation Mode This area indicates the DVD recorder’s current mode of ope
ration.
Use RECORDER MODE from the DISPLAY MENU screen to indicate whether or not
this is to be displayed.
NO DISC : The DVD recorder currently contains no disc.
EJECT : The current disc is being ejected.
OPE OFF : Operate Off mode
STOP : Stop mode
REC : Recording mode
REC PAUSE : Recording Pause mode
PLAY : Playback mode
STL : Still mode
FWD × 3 : Fast-forward play at 3 times normal speed
FWD × 15 : Fast-forward play at 15 times normal speed
REV × 3 : Fast-reverse play at 3 times normal speed
REV × 15 : Fast-reverse play at 15 times no
rmal speed
SLOW FWD 0.50 : Slow-forward play at 0.5 times normal speed
SLOW FWD 0.06 : Slow-forward play at 0.06 times normal speed
SLOW REV 0.50 : Slow-reverse play at 0.5 times normal speed
SLOW REV 0.06 : Slow-reverse play at 0.06 times normal speed
LOADING : A disc is being loaded.
MENU
DISPLAY
ON
TITLE/CHAPTER
ON
RECORDER MODE
TIME+DATE
ON
TIME/DATE
REMAIN
ON
DATE STYLE
MM/DD/YY
(DD/MM/YY:
E-model)
DISPLAY MENU
17
Status Messages (continued)
000 min
04/05/04
11:20:00
TITLE 1 0:11:22
CHAPTER
1 0:11:22
REC
4
3
2
5
Status Messages
Title number / Chapter
number / Counter
Date / Time
Remaining time
REC CONTROL panel
No. Item Description
2
3
4
5
Use TITLE/CHAPTER from the DISPLAY MENU screen to indicate whether or not this
is to be displayed.
Recording mode: The title number and chapter number currently being recorded are
displayed together with the elapsed title-recording time (in hours,
minutes, and seconds).
Playback mode : The title number and chapter number currently being played are
displayed together with the elapsed title-playback time (in hours,
minutes, and seconds).
Use TIME/DATE from the DISPLAY MENU screen to select the way in which the date
and time are displayed.
OFF : No information is displayed.
DATE : Only the date is displayed.
TIME : Only the time is displayed.
TIME+DATE : Both date and time are displayed.
● The date display style can be changed using DATE STYLE from the DISPLAY MENU
screen.
Recording mode: The date and time from the internal clock are displayed.
Playback mode : The date and time of disc finalizing are displayed.
Use REMAIN from the DISPLAY MENU screen to indicate whether or not this is to be
displayed.
Recording mode : The amount of video that can still be recorded on the current disc is
displayed (in minutes).
Playback mode : Not displayed
* Remaining time is to be used as a general guide, not as an exact figure.
Provided that a recordable disc has been inserted, this panel will be displayed whenever
REC CONTROL from the REMOTE MENU screen is set to ON.
The REC CONTROL panel can be used to control recording operations. (☞ Page 41)
