81
RECORDER MENU (2/2) screen
Parameter Possible settings Description
Y/C TERMINAL S1
MODE [S2]
Y C TM S1
[S2]
THUMBNAIL [NORMAL]
FORM V CUT
H CUT
V+H CUT
THUMB [NOR]
VCUT
HCUT
V+H
AUDIO [1,2ch
† 1,2ch]
CHANNEL (DV) 3,4ch † 1,2ch
DV CH [1 2]
3 4
AUDIO REC VOL. [BOTH]
MODE INDEPENDENCE
VRMODE [BOTH]
INDE
DISC IN ACTION [MENU]
TITLE
DISCIN [MENU]
TITL
TITLE END [MENU]
REPEAT
TI END [MENU]
REPT
BACK
This parameter is used to set the specification for the DVD recorder
’s VIDEO Y/C
INPUT terminal in order to enable the recording of wide-screen discrimination signals.
S1 : S1 terminal mode is to be adopted. A discrimination signal for normal video
with a 4:3 aspect ratio and squeezed video is to be recorded.
S2 : S2 terminal mode is to be adopted. A discrimination signal for normal video
with a 4:3 aspect ratio, squeezed video, and letterbox video is to be recorded.
Squeezed video : 16:9 wide-screen content with the left and right sides
compressed for normal aspect screens.
Letterbox video : Content with the top and bottom of the screen blackened out.
Thumbnail creation method for chapter and title menus during wide-signal recording
is selected.
NORMAL : The input signal is to be converted into thumbnails without modification.
If the input video has an aspect ratio of 4:3, the corresponding thumbnails
are also to have this aspect ratio.
V CUT : In this case, the top and bottom of the video content is to be removed to
form thumbnails.
H CUT : In this case, the left and right of the video content is to be removed to
form
thumbnails. (SQUEEZE)
V+H CUT : In this case, the top, bottom, left, and right of the video content is to be
removed to form thumbnails. (LETTER BOX)
This parameter is to be set when recording an audio signal from the DV IN/OUT
terminal.
Specifically, it indicates whether the signals from channels 1 and 2 or from channels
3 and 4 are to be recorded. (Only available for 32 kHz)
1,2ch †
1,2ch : Channels 1 and 2 are to be recorded.
3,4ch † 3,4ch : Channels 3 and 4 are to be recorded.
This parameter is used to select the method for adjustment of audio recording levels.
Specifically, both channels can be adjusted while maintaining the same level, or
each channel can be adjusted independently.
BOTH : Both channels are to be adjusted while maintaining the same
level.
INDEPENDENCE
:
Both channels are to be adjusted independently.
This parameter is used to indicate the action to be taken when a completed (i.e.,
finalized) disc is inserted into this DVD recorder or another DVD player. In order to be
effective, this setting must be made during the recording process.
MENU : The title menu is to be displayed.
TITLE
: Playback of the main content is to begin.
This parameter is used to indicate the action to be taken when playback of a title on
a completed (i.e., finalized) disc has ended. In order to be effective, this setting must
be made during the recording process.
MENU : The title menu is to be displayed.
REPEAT : Playback is to be repeated within the current title.
This button is used to return to the RECORDER MENU (1/2) screen.
82
Setup Menu
REMOTE MENU screen
The following table identifies and describes the parameters that may be set using the REMOTE MENU screen.
Top half : Appearance on monitor screen
Bottom half : Appearance on LCD display
[ ] : Default setting
Parameter Possible settings Description
REMOTE SELECT [OFF]
9PIN(MASTER)
DV(MASTER)
DV(SLAVE)
DV(TRIGGER)
REMOTE [OFF]
9PIN
DVM
DVS
DVT
REC CONTROL [OFF]
ON
REC [OFF]
ON
REM FF/REW [FF/REW]
MODE SEARCH
SEARCH [F R]
SEA
MENU
This parameter is used to select a method for controlling external devices connected
via the RS-422A REMOTE terminal or the DV IN/OUT terminal).
OFF : Control is not to be carried out via the RS-422A REMOTE terminal
or the DV IN/OUT terminal. This is the standard setting for normal
operation.
9PIN(MASTER): This setting is made when recording audio and video from a VCR
connected to the RS-422A REMOTE terminal. When selected,
the REMOTE CONTROL (9PIN MASTER) screen appears, and
this screen can be used to carry out recording operations.
DV(MASTER)
:
This setting is made when recording audio and video from a DV
camera or video connected to the DV IN/OUT terminal.
When selected, the REMOTE CONTROL (DV MASTER) screen
appears, and this screen can be used to carry out recording
operations.
DV(SLAVE) : This setting is made when recording audio and video from a non-
linear editor connected to the DV IN/OUT terminal. When selected,
the REMOTE CONTROL (DV SLAVE) screen appears. In addition,
the BD-X200 will become the slave device and will be controlled
by the non-linear editor.
DV(TRIGGER) : This setting is made when the BD-X200 is connected to a DV
camera featuring a DV record triggering function, and it allows
this DVD recorder to record video from the camera in response to
operation of its trigger button.
Note
When setting this item to 9PIN (MASTER), DV (MASTER) or DV (SLAVE), the video
output image becomes the REMOTE CONTROL screen display. However, video input
can be checked by press and holding the REC button while DVD Recorder is stopped
and viewing the encode output.
This parameter is used to indicate whether or not the REC CONTROL panel is to be
displayed on the monitor screen.
ON : The REC CONTROL panel is to be displayed only when a recordable disc
has been inserted and the DVD recorder is in Stop, Recording, or Recording
Pause mode.
OFF : The REC CONTROL panel not to be displayed.
This parameter is used to select the command output via the RS-422A REMOTE
terminal or DV terminal when the FF or REW button is pressed on the REMOTE
CONTROL (9PIN MASTER/DV MASTER) screen.
FF/REW :A
FF or REW command is to be output accordingly.
SEARCH :Aforward-search or reverse-search command is to be output accordingly.
This button is used to return to the Setup Menu screen.
