Control reference guide
(1) Cassette eject button (<, EJECT) . . . . . . . . . . . . . . . . . l 22
(2) Disc tray open/close button (<, OPEN/CLOSE) . . . . . . l 22
(3) Stop button (). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . l 30, 34
(4) Play/t1.3 button (1) . . . . . . . . . . . . . . . . . . . . . . . . . l 30, 34
(5) Recording button (¥, REC) . . . . . . . . . . . . . . . . . . . . l 23, 50
(6) DVD/VHS POWER on/off button (Í/I, POWER) . . . . . . . l 16
To switch the unit from on to standby mode or vice versa.
In the standby mode, the unit is still consuming a small
amount of power.
(7) IN2 input terminals (IN2) . . . . . . . . . . . . . . . . . . . . . . . . . l 50
(8) DVD-SEARCH, VHS-REW/FF buttons (V/6, 5/W)
(9) Channel up/down buttons (CH, X, W). . . . . . . . . . . . . . . l 35
(10)DVD/VHS drive indicator
Lights when the DVD or VHS drive is selected.
(11)DRIVE SELECT button
Drive changes each time you press [DRIVE SELECT].
(12)Connector for a digital video (DV) camcorder . . . . . . . l 50
(13)One Touch Transfer (copying) operation button
From VHS to DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . l 45
From DVD to VHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . l 47
Common to DVD/VHS
[A] Recording mode indicator
DVD:
XP, SP, LP, EP: (l 24)
XP SP LP EP (all on): FR mode (l 27)
VHS:
SP, LP°, EP, VP: (l 24)
° Playback only
[B] TV indicator
The indicator lights during the TV mode and it goes out during
the VCR mode. You can switch the mode by using [VCR/TV].
(l 21)
[C] Main display
Current time
Disc recording and play counter
VHS recording and play counter
Transfer (Copying) messages
Miscellaneous messages, etc.
VHS
(1) Scheduled recording indicator ( ) (l 28)
On:
When a scheduled recording program is registered and
recordable tape is inserted.
Flashes:
The scheduled recording indicator flashes when the unit cannot
go to scheduled recording standby (e.g. there is no tape, etc).
(2) Tape indicator
(3) Tape operation status
DVD
(1) Scheduled recording indicator ( ) (l 28)
On:
When a scheduled recording program is registered and a
recordable disc is inserted.
Flashes:
The scheduled recording indicator flashes when the unit cannot
go to scheduled recording standby (e.g. there is no disc, etc).
(2) Disc operation status
(3) Disc indicator
Main unit
CH
CH
POWER
DRIVE
SELECT
REC
㪛㪭㪛
㪭㪟㪪
OPEN/CLOSE
EJECT
S VIDEO
IN 2
VIDEO
/MONO
AUDIO
R
L
COPYING
COPYING
(2)
(1)
(5)
(3)
(4)
(13)
(6)
(7)
(8)
(9)
(11)
(12)
(10)
Remote control
signal sensor
Cassette compartment Disc tray
The unit’s display
The unit’s display
(2)
(3)
(2)
(3)
(1)(1)
[A]
[B]
[C]
