Chapter 4 153
ESA Functional Tests
Resolution Bandwidth Switching Uncertainty
ESA Functional Tests
5. Repeat step 3 and 4 for each of the remaining resolution bandwidth and span settings
listed in Table 4-6. The
∆ Mkr 1 amplitude reading should be within the range indicated
in the table “Test Limits” on page 151.
Table 4-6 Resolution Bandwidth Switching Uncertainty Worksheet
Resolution
Bandwidth
Setting
SPAN
Setting
∆ Mkr 1 Amplitude
Reading
1 kHz 50 kHz 0 (Ref)
3 kHz 50 kHz
10 kHz 50 kHz
30 kHz 500 kHz
100 kHz 500 kHz
300 kHz 5 MHz
1 MHz 10 MHz
3 MHz 10 MHz
