PRV-LX1
En
Writer 1
Output Board
(optional)
Input Board
(optional)
Writer 2
Video Monitor
Keyboard/mouse
(USB connector)
HDD (USB connector)
Internal HDD
REC monitor / GUI display
Note:
Note:
Supported discs:
DVD-R (general use),
DVD-RW
* (Must be purchased separately)
At present, GUI is not
output from the VGA
(GUI) output
connectors.
* (Must be purchased separately)
* (Must be purchased separately)
* (Must be purchased separately)
* (Must be purchased separately)
Video in/out
Component video
Composite video
S-video
DV
Audio in/out
RCA
XLR
DV
Video out
SDI
Audio out
SDI, AES/EBU
Video in
SDI
Audio in
SDI, AES/EBU
Video out
Component video
Composite video
S-video
Remote
control unit
SDI AES/EBU Input Board
PRA-BD11
SDI AES/EBU Output Board
PRA-BD12
By installing the optional SDI
AES/EBU input board (PRA-
BD11) in the unit’s expansion
slots, the PRV-LX1 can be
upgraded to support input of
SDI video signals and SDI/AES
EBU audio signals.
Note:
By installing the optional SDI
AES/EBU output board (PRA-
BD12) in the unit’s expansion
slots, the PRV-LX1 can be
upgraded to support output of
SDI video signals and SDI/AES
EBU audio signals.
Writer 2
(optional for single-
DVD-drive model)
Expansion DVD-R/RW writer unit
* (Must be purchased separately)
PRA-DW11
Example of System Composition and Recording Component Setup
7 System Composition
An exterior control system can be created using
REMOTE/DV protocols*.
* Operating compatibility is not guaranteed for all
components equipped with REMOTE/DV connectors.
Check Pioneer’s website for a list of components and
systems with confirmed operational compatibility.
* Control from editing equipment is not supported.
[System Example]
REMOTE
Video
Audio
DV
* BETACAM, Digital BETACAM, and DVCAM are registered trademarks of Sony Corporation.
* DVCPRO is a registered trademark of Matsushita Electric Corporation.
* Check Pioneer’s website for a list of components and systems with confirmed operational compatibility.
