22
PRV-LX1
En
Functions
[Main Unit Setting Functions]
7 System Settings (Operation Details: page 29)
• These items allow setting of mouse and keyboard, function keys of a keyboard assignments, network
settings, and other defaults. Displaying system information and formatting the hard disk can also be
performed here.
1 System Setting: Use to perform settings including keyboard, mouse, and main unit clock.
2 F-Key Set: Use to assign unit functions to the function keys of a keyboard.
3 Network: Use to perform network settings (when an optional network is installed).
4 UPS Setting: Use to perform settings when connected to a designated uninterrupted power
system (UPS).
5 Information: Display system information.
6 HDD Tools: Use to erase user data and perform file system checks on the hard disk drive.
Note 1:
A mouse and keyboard are not included. Most commercially available mouses and keyboards (with USB connector) may
be used.
Note 2:
When connecting a UPS, please purchase the Smart-UPS 700VA (SU700NET) manufactured by AMERICAN POWER
CONVERSION CORP. (APC).
7 Operation Settings
• Use to make settings required when connecting the PRV-LX1 to other components, and to perform
operation settings.
1 Control Setting: Settings required when connecting this unit to a source component (page 40).
* Example of connections with local settings
* Example of connections with remote settings
Note 3:
There are limitations on supported commands. In addition, control may not be possible depending on the model.
Please check our web site for information on devices for which connection has been confirmed.
Operations other than manual forced shutdown may not be accepted if auto capture is performed with a device for which
connection has been confirmed. Manual forced shutdown may damage the contents of HDD recordings.
2 Video Setting: Use to perform settings for Video and OSD output (page 52).
3 HDD Recording: Use to enable/disable settings for time shift playback (page 49).
4 Info Language: Set GUI display language (page 32).
Note 4:
When GUI language is set to Japanese, the information area and dialogue displays are shown in Japanese, and Japanese
language input is also supported.
VTR or Computer
PRV-LX1
Control
PRV-LX1
Connected VTR
No control
PRV-LX1
Connected VTR
Control
