26
PRV-LX1
En
Status Confirmation Using Onscreen Display (OSD)
By pressing the DISPLAY button on the unit’s front panel or on the remote control unit, the onscreen display
(OSD) will be projected on the monitor screen. The OSD permits confirmation of the unit’s current setting
status, as as well as recording/playback conditions.
7 Idling Condition Recording-Setting Confirmation Screen
When the unit is in the idling condition, pressing the DISPLAY button causes a listing of the unit’s current
Status (settings) to be displayed. This display allows the user to check settings before operating the unit, yet
without the need to enter the Function Menu, thus permitting more efficient operation.
When in the idling condition, the OSD screen is composed of two pages. The first two times the DISPLAY
button is pressed, the OSD alternates between the two pages; when the button is pressed a third time, the
OSD is turned off.
Note 1:
When the destination drive is DVD, the project name is not displayed.
Project names are displayed only when HDD is designated as the destination drive.
Main unit button
Remote control unit
Drive selected
Project name
(Note 1)
Video source
Video encoding rate
Video filter label
Audio input source
Audio encoding format
OSD Page 1
Remaining HDD capacity
Remaining recording time
Time code input source
Input time code data
External sync
Control mode
Video aspect ratio
Chapter mark input
method
OSD Page 2
