Importing Image Data, Edit Lists
This function allows the importing of image data
from CD/DVD discs, or a web browser with FTP
connection from a computer linked to an online
network. These images can be then stored in the
recorder’s menu library for use as DVD menu layout
images and DVD menu background images. Edit list
files can be similarly imported.
When using FTP to download images from the
Internet, go to the SET UP section = [System] =
[Network] command and confirm that network is set
to “ON”. Also, The displayed IP address will be the
connection destination. The user name and
password necessary for FTP connection is as
follows:
User Name: PRVUser
Password: prv-lx1
Following establishment of FTP connection, store
files relating to the DVD menu in the menu folder;
files regarding edit lists should be stored in the EDL
folder.
Files obtained via FTP from the network are
temporarily stored in the hard disk drive’s Import
Directory; then, the “Import Directory” is
designated using the Function Menu’s APP section
[Cpy/Impt/Bkup] = [Menu Import] = [Source]
command; the files to be added to the menu library
are selected, and the Add to Library button is
pressed to begin importing. The same procedure is
used for importing Edit List files. When “DVD1” or
“DVD2” is designated as the source, import is
begun from the disc loaded in the respective drive
when the Add to Library button is pressed.
Note 1:
When importing image data or edit lists, if “DVD1”
or “DVD2” is selected as the [Source], the contents
[Source File] will not be imported merely by
inserting the disc. The drive must be selected once
again from [Source] after the disc is inserted in the
drive.
Note 2:
Importing a file with the same name as a file already
on the disk overwrites the existing file.
Note 3:
Characters usable in import file names are limited to
single-byte alphanumerics, plus periods (.) and
underscore characters (_) only.
Note 4:
Place the files that are to be imported in the top
directory (root directory) when a disc is used for
importing. Files placed in a directory other than the
top directory are not imported.
Note 5:
Avoid using FTP during recording, since the system
may become unstable.
Using APP section
=
[
Cpy/Impt/Bkup
]
=
[Menu Import]
=
[Type] to select background image
APP section = [
Cpy/Impt/Bkup
] = [Menu Import]
= [Source]
Using APP section
=
[Cpy/Impt/Bkup]
=
[Menu Import]
=
[Source File]
to select import file
