27
PRV-LX1
En
7 OSD during Recording
When the DISPLAY button is pressed during recording, the OSD projects the unit’s recording status and
playback condition (during time shift playback), thus allowing confirmation of these items.
In the recording mode, the OSD screen is composed of two pages, a simple (reduced clutter) page, and a
detailed information page. The first two times the DISPLAY button is pressed, the OSD alternates between
the two pages; when the button is pressed a third time, the OSD is turned off.
Status Confirmation Using Onscreen Display (OSD)
Note 2:
The recording time is the same as the time for the input video image;
this differs from the output video image time (which is subjected to
encoding/decoding).
Note 3:
Playback status is shown only during time shift playback.
Main unit button
Remote control unit
Recording status Recording title/chapter Recording time
(Note 2)
Playback
status
(Note 3)
Playback title/chapter
(Note 3)
Playback time
(Note 3)
OSD during Recording (page 1)
Note 4:
Playback status is shown only during time shift playback.
Playback status
Playback title/chapter
(Note 4)
Recording title/chapter
Playback time
(Note 4)
Recording time
Video input Audio input
Remaining
HDD capacity
OSD during Recording (page 2)
Remaining recording time
Recording status
(Note 4)
Video encode rate Video filter level
