Onkyo L-MS30 DVD Player User Manual



15
& RANDOM button [56, 60]
Press to activate random playback.
* REPEAT button [41, 47, 52, 56–57, 60]
Use to set the repeat mode.
( A-B button [47, 52]
Press at the beginning and end of the section you want to repeat or
to mark a location you want to return to.
) B.MARK button [48–49, 53]
Use to set the Book Mark function.
_ VOLUME 5/a buttons [32]
For adjusting the volume.
+ MENU/PBC button [27, 37, 39]
Use to display or close the DVD menu. When a Video CD is
loaded, press to turn on and off the PBC function.
¡ ON SCREEN button [51, 58]
Press to display information about the disc set in the unit.
8 button [36, 39]
Press to pause disc playback.
£ £ button [35–37, 39]
Press to start or resume playback.
¢
4
/
¢
buttons/ TUNER PRESET
2
/
3
[38, 40, 41, 43–44]
During playback of DVD, CD and Video CD, press 4 to go
back to a previous chapter/track and ¢ to advance to the next
chapter/track. When AM or FM is selected, press to select preset
channels.
AUDIO button [50, 55]
Press to select various audio languages on a disc. When playing a
VCD, press to select the audio channel.
§ SUBTITLE button [27, 50]
Press to select various subtitle language on a disc.
1 STANDBY/ON indicator [26]
Red: The unit is in standby mode
Green: The unit is in operation
2 OUTPUT LEVEL knob
Use this knob to adjust the output level of subwoofer.
3 LINE INPUT jack
Connect this jack to subwoofer pre out of DR-L30.
4 POWER switch (ON/OFF) [26]
Press this switch to the ON position to turn on the power. Press it
to the OFF position to turn off the power.
5 POWER cord
Subwoofer
OUTPUT
LEVEL
LINE
INPUT
MIN
MAX
POWERED
SUBWOOFER
MODEL NO. SKW
-
L
30
POWER
ON OFF
1
2
3
4
5
