Onkyo L-MS30 DVD Player User Manual



63
Main unit
Symptoms Causes Remedies Pages
Playback does not start when
the
£/8 button is pressed.
There is no disc in the DVD receiver.
There are no signals recorded on the side of
the disc being played.
Load a disc and press the
£/8 button.
Turn the disc over and properly place it on the
disc tray.
36
36
Playback starts but no
image/sound is seen heard.
The TV is not turned on.
The connection cords are not properly
connected.
Turn on the TV.
Properly reconnect the connection cords.
17–23
The picture is disrupted
when the image is fast
forwarded or fast reversed.
The picture is slightly disrupted during fast
forward and fast reverse operations.
This is not a malfunction.
No sound is heard. The audio output cords are not properly
connected.
The player is in a special playback mode.
Properly connect the audio cords.
•Press the
£/8 button to resume normal
playback mode.
20
The picture does not look
good or the picture/sound
quality is poor.
A nearby device is generating noise.
The disc is dirty.
The disc is damaged.
There is condensation on the optical lens.
Separate this unit as far as possible from the
device you think is generating the noise.
Refer to the “Cleaning Discs” section and
wipe dirt from the disc.
Use a new disc.
Refer to the “Notes on Moisture
Condensation” section and evaporate the
condensation.
11
3
It takes a while for the disc
to start playing.
Time is required for the unit to detect the disc
type and size and for the rotation of the motor
to stabilize. This is not a malfunction.
Approximately 10 to 20 seconds are required
for a disc to start playing, although the time
differs depending on the disc.
The tray opens
automatically.
The disc is not placed horizontally. Properly place the disc on the tray. 36
The top and bottom of the
screen cannot be seen, or the
screen becomes black-and-
white.
The video format of the disc being played
does not match that of the connected TV
monitor.
Refer to the “To set the TV system” section,
and use a disc with the appropriate video
format for your TV or a TV with the
appropriate video format for the disc.
27, 29
The subtitle is not displayed. The DVD disc being played does not contain
the recording of subtitles.
The subtitle mode is set to off.
The subtitle cannot be displayed when the
DVD disc being played does not contain the
recording of subtitles.
Press the SUBTITLE button to switch on the
subtitle mode.
50
The voice (or subtitle)
language cannot be changed.
The DVD disc being played does not contain
the recording of more than one audio (or
subtitle) language.
The voice (or subtitle) language cannot be
changed when the DVD disc being played
does not contain the recording of more than
one voice (or subtitle) language.
The viewing angle cannot be
changed.
The DVD disc being played does not contain
the recording of more than one angle.
You are attempting to switch the angle in a
DVD section where more than one angle is not
recorded.
The viewing angle cannot be changed when
the DVD disc being played does not contain
the recording of more than one angle.
More than one viewing angle may be recorded
only in limited sections in a disc.
Playback will not start even
after a title is selected.
A viewing restriction (PARENTAL) has been
set for the disc.
Check the viewing restriction level
(PARENTAL) setting.
31
