Onkyo L-MS30 DVD Player User Manual



29
TV DISPLAY
NORMAL/PS (Pan Scan)
Select when a 4:3 TV is connected. Displays pictures cropped to
fill your TV screen. Either or both sides of the picture are cut off.
This function is only available when using a disc that supports
Pan Scan.
NORMAL/LB (Letter Box)
Select when a 4:3 TV is connected. Displays wide screen images
with masking bars above and below the picture.
WIDE
Select when a 16:9 wide TV is connected.
Notes
The displayable picture size is preset on each DVD video.
Therefore, the playback picture of some DVD videos may not
conform to the picture size you select.
When you play a DVD video recorded in the 4:3 picture size only,
the playback picture always appears in the 4:3 picture size
regardless of the TV shape setting.
If you select WIDE and you own a 4:3 TV set, the DVD playback
picture will be horizontally distorted during playback. Images will
appear to be horizontally compressed. Make sure the TV shape
conforms to the actual TV in use.
PIC MODE
This adjusts the screen quality according to the material
being played back.
AUTO
The picture quality is adjusted automatically.
FILM
Choose this setting to reproduce the picture quality of film
material.
VIDEO
Choose this setting to reproduce the picture quality of video
material.
SMART
Choose this setting to reproduce progressive and interlaced
materials with limited motion.
SSMART
Choose this setting to reproduce progressive and interlaced
materials with motion (motion adaptive deinterlacing).
ANGLE MARK
ON
When a picture recorded in different angles is played back, is
displayed on the screen.
OFF
is not displayed on the screen. ( is displayed when the
camera angle is changed.)
OSD LANG
Select the On-Screen Display language.
ENGLISH
CHINESE
CAPTIONS (NTSC only)
Some DVD videos contain special subtitles, an enhancement of
closed captions for hearing impaired persons. The DVD Player
automatically displays these special subtitles by setting this item to
ON.
ON
The extended subtitles are displayed automatically.
OFF
The extended subtitles are not displayed.
SCR SAVER (Screen Saver)
If you pause a picture for a long time, the screen saver automatically
operates by setting this item to ON.
ON
The screen saver is enabled.
OFF
The screen saver is disabled.
General Setup
