Connecting Speakers
Attaching the fitting
Using the screws provided, attach the fittings to the rear of the
speaker cabinet. You can secure the speakers so they do not move by
stacking up two of the provided satellite speaker cork stoppers and
attaching them as indicated in the illustration. Attach the fittings in
two places on the center speaker (SKC-L30) and one place on the
satellite speaker (SKM-L30).
Note
When mounting speakers on the wall, be sure to check the strength of
the wall before mounting. The weight the screws are able to support
differs depending on the material used for the wall and the position of
the wall supports. Make sure you use sturdy, long screws with a head
diameter of no more than 10 mm and a shaft diameter of no more
than 4 mm. (If you are unsure about which screws to use, ask a shop
assistant for advise.)
The wall-mount fittings
Wall-mount fitting
Screw
Cork stopper
SKM-L30
Wall-mount fitting
SKC-L30
Screw
Cork stopper
