Onkyo L-MS30 DVD Player User Manual



46
Enjoying the Sound Effects
Press SURROUND.
Each press switches the modes as shown below.
(At the time of PCM source or Dolby Digital 2ch source)
DOLBY PL II MOVIE
DOLBY PL II MUSIC
STEREO
(At the time of Dolby Digital 5.1ch source)
Dolby Digital
STEREO
(At the time of DTS source)
DTS
STEREO
When playing a source encoded in Dolby Digital or DTS, the
surround mode is set to “Dolby Digital/DTS” automatically.
Note
Don’t change the listening mode while recording with a VCR.
Tip
The Input/Speaker indicator becomes an input indicator at time of
DOLBY DIGITAL and DTS source and a speaker indicator at all
other times.
Description of Dolby Pro Logic II:
Music mode
Panorama mode
Expands the image of front-channel stereo to the surround speakers
to create a sound environment that fills your surroundings. (To
change the Panorama mode, press SETUP button at the time of
Dolby Pro Logic II Music mode. Display the PANO R OFF or ON,
then press the LEVEL +/– buttons to select ON or OFF.)
Dimension
This controls the balance between the Front and Rear in 2 steps on
the front and 2 steps on the rear. Set this parameter to one of the
Front steps if the surround effect is too strong, or to one of the Back
steps if it is too weak. (To change the Dimension, press SETUP
button twice at the time of Dolby Pro Logic II Music mode. Display
the DIMEN 0 (or other value), then press the LEVEL +/– buttons to
select F-2, F-3, R-2 or R-3.)
Center Width
The center channel signal can be divided and distributed to the Front
L/R channels.
The adjustment for distributing the center channel signal to the front
channels can be applied in eight steps from 0 to 7. Use this
adjustment when the center image seems to be too strong. (To change
the Center Width, press SETUP button 3 times at the time of Dolby
Pro Logic II Music mode. Display the C WIDTH 3 (or other value),
then press the LEVEL +/– buttons to select 0 ~ 7.)
The DVD receiver will automatically detect the sound system when
DOLBY DIGITAL Surround ( ), DTS Surround ( ), or
PCM/MP3 DIGITAL (2 channel digital stereo) is played back. The
corresponding sound system indicator lights in the DVD receiver’s
display.
Press A.CONTROL.
Each press of the button changes the acoustic mode as follows:
A CTRL 1 = A CTRL 2 = OFF = A CTRL 1
Selecting Surround Mode
A.CONTROL
SURROUND
Main unit
Remote controller
Checking the Sound System of the
Playing Source
Surround
mode
Source
DISC INPUT
Dolby
Digital
5.1ch
Dolby
Digital
2ch
DTS
VCD/
CD
Analog/
PCM
source
Dolby Digital
DTS
PL II
STEREO
Adjusting the Sound
