Pioneer DVR-RT501-S DVD Recorder User Manual



Before using your unit
01
12
En
AV3
Parts and functions
Rear
Front
STANDBY/ON
button
AUDIO (L/R)/VIDEO
IN (AV3) jacks
VCR EJECT button
DVD S-VIDEO IN (AV3) jack
VCR/DVD button
OPEN/CLOSE button
PLAY button
STOP button
FF (Fast Forward) button
REW (Rewind) button
REC button
CHANNEL +/–
buttons
Disc tray
Cassette Loading Slot
VCR indicator
DUBBING button
Display window
IR Remote sensor
DVD indicator
