Specifications
Note: The specifications and design of this product are subject to change without notice, due to improvement.
GENERAL
Power supply:
Power consumption:
Weight:
Dimensions:
Operating temperature:
Operating humidity:
Input Level:
Output Level:
Program:
Power off memory:
VCR section
Signal system:
Video head:
Audio track:
Channel coverage:
RF channel output:
F.FWD/REW Time:
Hi-Fi Frequency Response:
Hi-Fi Dynamic Range:
DVD section
Signal system:
Applicable disc:
Recording format:
Recording discs:
Recording time:
(based on a 4.7GB disc)
Audio characteristics
frequency response:
S/N Ratio:
Harmonic distortion:
Wow and flutter:
Output:
Pickup:
ACCESSORIES:
AC 230V 50Hz
Operation: 31W
Standby: 5.5W (if display window is off.)
5.0 kg
Width : 430 mm
Height : 90 mm
Depth : 320 mm
5°C to 35°C
Less than 80% RH
SCART-socket: Video : 1 Vp-p, 75 Ω
Audio : 500 mV, 50k Ω
Audio IN jack: 500 mV, 50k Ω
SCART-socket: Video : 1 Vp-p, 75 Ω
Audio : 500 mV, 1k Ω
Audio OUT jack: 500 mV, 1k Ω
12 programs / 1 month
Approx. 30 min
PAL
NTSC tape playback with PAL/60 Hz
4 Rotary Heads
Hi-Fi Sound - 2 Tracks / MONO Sound - 1 Track
21-69
UHF channel 36 (23 to 69)
Approx. 1 minute and 12 seconds (with E-180 Cassette Tape)(at+25˚C)
20Hz to 20,000Hz
More than 75dB
PAL
DVD (12cm, 8cm), CD (12cm, 8cm)
DVD-Video Recording (VR mode)
DVD-VIDEO (Video mode)
DVD-RW, DVD-R
XP: Approx. 60 min
SP: Approx. 120 min
LP: Approx. 240 min
EP: Approx. 360 min
DVD: 4Hz - 22kHz
CD: 4Hz - 20kHz
90dB
Less than 0.06%
Less than 0.01% Wrms
Video :(RCA) 1 Vp-p/75 Ω
Audio :(RCA) –12 dBm/1k Ω
Digital Audio : 0.5Vp-p/75 Ω
CD : Wavelength: 780 nm
Maximum output power: 8.5 mW
DVD : Wavelength: 660 nm
Maximum output power: 120 mW
Remote control x 1
75 Ω Coaxial Cable x 1
21 pin SCART Cable x 1
Dry cell battery (AAA/R03) x 2
Operating Instructions
