51
CHAPTER 6 INSTALLATION AND WIRING
6
6.4 Examples of Wiring Between a Controller and External Input Terminals
(3) When the controller is a line driver type
A18(A12)
24V
B18(B12)
12V
A17(A11)
5V
B17(B11)
PRSTCOM
Preset
Shield
OUT
E
Controller
A16(A10)
24V
B16(B10)
12V
A15(A09)
5V
B15(B09)
FUNCCOM
Function start
Shield
OUT
E
OUT
OUT
Shielded twisted pair cable
Shielded twisted pair cable
LD62D
In parentheses, terminal numbers of channel 2 are shown.
