3 - 50 3 - 50
MELSEC-Q
3 SPECIFICATIONS
(2) Multiplexed remote master station multiplexed remote sub-
master station
(a) Cyclic transmission (LB/LW/LX/LY periodic communication)
The transmission delay time of B/W/Y communication is the sum of the
following:
• Scan times of a multiplexed remote master station and a multiplexed
remote sub-master station (Except for the link refreshing time)
• Link refresh times of a multiplexed remote master station and a
multiplexed remote sub-master station
• Link scan time of a multiplexed remote master station
Calculate the sum as below:
1) In the case of END synchronization
[Transmission delay time of B/W/Y communication] (END synchronization)
1) Multiplexed remote master station Multiplexed remote sub-master station:
Transmission delay time (T
DM1)
[Multiplexed remote master station side scan time (Sm) > Link scan time (LS)]
T
DM1 = (Sm + m) + LS + (Ss 2 + s) [ms]
[Multiplexed remote master station side scan time (Sm) < Link scan time (LS)]
T
DM1 = (Sm + m) round up [LS/(Sm + m)] + LS + (Ss 2 + s) [ms]
2) Multiplexed remote sub-master station
Multiplexed remote master station:
Transmission delay time (T
DS1)
[Multiplexed remote master station side scan time (Sm) > Link scan time (LS)]
T
DS1 = (Ss + s) + (Sm + m) 2 + Sm [ms]
[Multiplexed remote master station side scan time (Sm) < Link scan time (LS)]
T
DS1 = (Ss + s) + (Sm + m) round up [LS/(Sm + m)] 2 + Sm [ms]
Sm :Multiplexed remote master station side scan time
Ss :Multiplexed remote sub-master station side scan time
m :Multiplexed remote master station side link refresh time
s :Multiplexed remote sub-master station side link refresh time
LS :Link scan time
round up :Round up decimal fraction of the operation result
[LS/(Sm + m)]
The above calculations are effective under the following conditions:
• There are no faulty stations.
• Transient transmission is not executed.
