MELSEC-Q
2 SYSTEM CONFIGURATION
2.1.2 Setting items
(1) Table 2.1 lists the setting items on the master module of the remote master station
(MR) and the parameter setting items on GX Developer.
Table 2.1 Remote master station setting items
Setting items Remote master station (MR) Reference
Network module switch
STATION NO. 0 Section 4.2.1
MODE
Section 4.2.2
Parameter setting on GX Developer
Setting the number of Ethernet/CC IE/MELSECNET cards
Network type
MELSECNET/H
(Remote master station)
Section 5.1.1
Starting I/O No.
Section 5.1.2
Network No.
Section 5.1.2
Total stations
Section 5.1.2
Group No. —
Mode
Section 5.1.2
Common parameters
Section 5.1.3
Supplementary setting
Section 5.1.4
Station specific parameters —
Refresh parameters
1 2
Section 5.1.5
Valid module during other station access Section 5.1.6
Interlink transmission parameters —
Routing parameters 3
: Always set,
:
Default setting,
:
Set as needed,
:
No need to set
1: Default values are not set in LX/LY. Set the refresh parameters.
2: Default values are preset for LB/LW.
The CPUs other than the Universal model QCPU may operate even if refresh
parameters have not been set.
For the operation and precautions, refer to Section 5.1.5 (3).
3: Refer to the Q Corresponding MELSECNET/H Network System Reference
Manual (PLC to PLC Network) (SH-080049).
