5 PARAMETER SETTINGS
Table 5.1 Remote master station network parameter setting items
Network station type
Parameter setting item
Remote master station
Reference
section
Settings with the network module
Section 4.3
Station number (STATION No.)
Section 4.3.1
Mode (MODE)
Section 4.3.2
Settings with GX Developer
Setting the number of modules (network type)
Section 5.1.1
Network settings
Section 5.1.2
Starting I/O No.
Section 5.1.2 (1)
Network No.
Section 5.1.2 (2)
Total stations
Section 5.1.2 (3)
Group No.
Section 5.1.2 (4)
Mode
Section 5.1.2 (5)
Common parameters
Section 5.1.3
Send range of each station (LX/LY settings)
Section 5.1.3 (1)
Send range of each station (LB/LW settings)
Section 5.1.3 (2)
Specify reserved station
Section 5.1.3 (3)
Supplementary settings
Section 5.1.4
Constant link scan
Section 5.1.4
Maximum No. of returns to system stations in 1
scan.
Multiplex transmission designation
Block send data assurance per station
Block receive data assurance per station
END asynchronous settings
Transient settings
Refresh parameters 3 4
Section 5.1.5
Valid module during other station access
Section 5.1.6
Interrupt settings
Section 7.7
Redundant settings
Section 5.1.7
Routing parameters
5
: Always set : Default setting exists : Set as needed : Setting not required
3: Default values are not set for LX/LY. Set the refresh parameters.
4: Default values are preset for LB/LW.
The CPUs other than the Universal model QCPU may operate even if
refresh parameters have not been set.
For the operation and precautions, refer to Section 5.1.5 (3).
5: For details, refer to the Q Series MELSECNET/H Network System
Reference Manual (PLC to PLC Network).
REMARKS
Always write network parameters to the remote master station.
