7 - 43 7 - 43
MELSEC-Q
7 APPLICATION FUNCTIONS
(5) Error codes detected by remote I/O module
Error code Error message LED status Description Measures
3400 REMOTE
PASS. ERR.
ERR. LED:
on
The head I/O number of the target
module in the remote password file is
set to other than 0
H to 0FF0H.
Change the head I/O number of the
target module to within the 0
H to 0FF0H
range.
3401 REMOTE
PASS. ERR.
ERR. LED:
on
Any of the following modules is not
mounted on the slot specified for the
head I/O number of the remote
password.
• Serial communication module of
function version B or later
• Ethernet module of function version B
or later
Mount any of the following modules in
the position specified for the head I/O
number of the remote password.
• Serial communication module of
function version B or later
• Ethernet module of function version B
or later
(6) Cautions when setting a remote password
(a) If the starting I/O No. is changed after the remote password is set, the
previous remote password set with the Ethernet module/serial
communication module becomes invalid.
(b) Only the remote password set for the directly connected module can be
canceled (unlocked) by remote operation of GX Developer. (The remote
password for the indirectly connected module cannot be canceled by
remote operation.)
