3 - 55 3 - 55
MELSEC-Q
3 SPECIFICATIONS
(b) When a master module is connected to extension base unit
Constant
CPU type
KM1
KM2
( 10
–3
)
KM3
( 10
–3
)
High Performance
model QCPU
Q02CPU 0.30 1.20 0.47
Other than above 0.13 0.97 0.53
Process CPU
0.13 0.97 0.53
Redundant CPU
Universal model
QCPU
Q00UJ/Q00U/Q01UCPU 0.16 1.06
Q02UCPU 0.16 1.06 0.39
Q03UD/Q03UDECPU 0.09 0.97 0.39
Other than above 0.09 0.97 0.33
POINT
The values in previous page are calculated on the basis that data are received from
all stations during one sequence scan.
When the link scan is long or when the sequence scan is short, data from all
stations may not be received within one sequence scan.
If this occurs, the actual link refresh time is less than the calculated value shown in
this section.
Remote I/O station link refresh time (r)
The remote I/O station link refresh time (r) does not affect transmission delay
time.
