7 - 42 7 - 42
MELSEC-Q
7 APPLICATION FUNCTIONS
(4) Setting procedure of remote password
"GX Developer" "Remote pass" "Remote password settings" screen
"Remote password detail settings" screen
(a) Setting screen
(b) Setting items
Item Setting Setting range/option
Password settings Enter a remote password 4 characters, ASCII code 1
Password active module
settings
Model name Select a model QJ71E71/QJ71C24/QJ71CMO
Start XY Set the module's top address. 0000H to 0FE0H
Detail
Available or N/A
User connection No. Set a connection No. for users Connection No.1 to 16
System connection
Auto open UDP port
Check the remote password valid port
FTP transmission port (TCP/IP)
GX Developer transmission port
(TCP/IP)
GX Developer transmission port
(UDP/IP)
HTTP port
1: Indicates the upper/lower-case characters (other than " ", i.e., space) that
can be input using the keyboard
POINT
For the details of the remote password function, refer to the manuals below.
• When the serial communication module is used:
Q Corresponding Serial Communication Module User's Manual (Application)
• When the Ethernet module is used:
Q Corresponding Ethernet Interface Module User's Manual (Basic)
