M2488 PRODUCT GUIDE MAINTENANCE AND SERVICING
April 1997 CG00000-011503 REV. A 8-43
8-11.1 Air Filter Remove and Replace Procedures
Refer to Figure 8-3 for location of the air filter.
8-11.1.1 Air Filter Removal
This procedure takes approximately five minutes to perform.
8-11.1.2 Air Filter Replacement
Figure 8-3. Air Filter Removal
STEP ACTION
1 Insert a screwdriver into the bottom left of the front panel under the air filter.
2 Push up with screwdriver, then remove air filter from top of front panel.
STEP
ACTION
1 Insert clean air filter though the top left of the front panel.
